System And Components
476-0084 EXHAUST GPS/N XP51-UP
Group No: 476-0084
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1263884 | 1 CAP AS-RAIN (EXHAUST) | 1 | |
| 2453512 | 2 GASKET (EXHAUST) | 1 | |
| 2473393 | 3 CLAMP AS (V-BAND) | 2 | |
| 3368526 | 4 BELLOWS | 1 | |
| 3869290 | 5 GASKET | 1 | |
| 4763014 | 6 MUFFLER AS | 1 | |
| 4766698 | 7 PIPE AS-EXHAUST | 1 | |
| 2460992 | TAPE (INSULATION) | ||
| 4798741 | 8 PIPE AS-EXHAUST | 1 | |
| 2460992 | TAPE (INSULATION) | ||
| 1757141 | 9 NUT-HEX FLANGE (M10X1.5-THD) | 12 | |
| 3383669 | 10 BOLT-FLANGE HEAD (M10X1.5X30-MM) | 12 | |
| 5P8245 | 11 WASHER-HARD (13.5X25.5X3-MM THK) | 16 | |
| 6V7673 | 12 BOLT (M12X1.75X50-MM) | 8 | |
| 6V8149 | 13 NUT (M12X1.75-THD) | 8 |
