System And Components
348-2912 AIR CLEANER GPS/N X3F1-UP
Group No: 348-2912
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4W5828 | 1 CAP-AIR CLEANER | 1 | |
| 6R3185 | 2 REDUCER | 1 | |
| 7S7755 | 3 HOSE | 1 | |
| 1454211 | 4 ADAPTER AS-FILTER | 1 | |
| 7J0204 | SEAL-O-RING | 1 | |
| 1505030 | 5 INDICATOR-AIR FILTER CHANGE | 1 | |
| 1692167 | 6 AIR CLEANER GP | 1 | |
| 2566453 | 7 SENSOR-TEMPERATURE (2-PIN)(AMBIENT AIR) | 1 | |
| 3638609 | 8 TUBE AS | 1 | |
| 3651047 | 9 BRACKET AS | 1 | |
| 1F0750 | NUT-WELD (3/8-16-THD) | 2 | |
| 3651048 | 10 BRACE | 1 | |
| 3651049 | 11 BRACE | 1 | |
| 3K0360 | 12 SEAL-O-RING | 1 | |
| 4L6454 | 13 BOLT (3/8-16X1-IN) | 6 | |
| 5P0599 | 14 CLAMP-BAND | 3 | |
| 5P1075 | 15 WASHER-HARD (10.2X22.5X3-MM THK) | 6 | |
| 5P3860 | 16 CLAMP-HOSE | 1 | |
| 7X0343 | 17 BOLT (5/8-11X1.25-IN) | 2 | |
| 7X0447 | 18 NUT (7/16-14-THD) | 4 | |
| 8T4122 | 19 WASHER-HARD (17X32X3.5-MM THK) | 2 | |
| 8T5360 | 20 WASHER (12X22.5X2.5-MM THK) | 8 | |
| 8T6973 | 21 BOLT (7/16-14X1.125-IN) | 4 | |
| 0681270 | 22 CAP (DRY COOLER) | 1 |
