System And Components
441-3571 LINES GP-AIRS/N X3F1-UP
Group No: 441-3571
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3279287 | 1 HOSE-AIR | 3 | |
| 3845285 | 2 BRACKET | 1 | |
| 3845286 | 3 BRACKET AS | 1 | |
| 8T3597 | NUT-WELD (M12X1.75-THD) | 2 | |
| 4413572 | 4 TUBE AS | 1 | |
| 4413573 | 5 TUBE AS | 1 | |
| 4413574 | 6 BRACKET | 1 | |
| 3293356 | 7 NUT (M12X1.75-THD) | 4 | |
| 3V1005 | 8 CLAMP-HALF | 6 | |
| 5P1076 | 9 WASHER-HARD (13.5X30X4-MM THK) | 4 | |
| 8T4139 | 10 BOLT (M12X1.75X30-MM) | 4 | |
| 8T4183 | 11 BOLT (M12X1.75X40-MM) | 2 | |
| 8T4189 | 12 BOLT (M8X1.25X20-MM) | 2 | |
| 8T4223 | 13 WASHER-HARD (13.5X25.5X3-MM THK) | 10 | |
| 8T4224 | 14 WASHER-HARD (8.8X16X2-MM THK) | 2 | |
| 8T4956 | 15 BOLT (M12X1.75X35-MM) | 4 | |
| 8T6703 | 16 CLAMP-HOSE | 6 |
