Assembly
100%

245-9775 HOUSING GP-FLYWHEELS/N MHM1-UP; MZM1-UP

Group No: 245-9775
Part NumberPart NameQty
31907851 SEAL GP-CRANKSHAFT (REAR)(FLYWHEEL HOUSING)1
16087082 BRACKET AS2
8T3490NUT-WELD (M10X1.5-THD)1
22512423 GASKET (FLYWHEEL HOUSING)1
56882124 HOUSING AS-FLYWHEEL1
1W31364A BAFFLE1
0S16195 BOLT (3/8-16X3-IN)2
1A51836 BOLT (3/8-16X4.75-IN)18
23144707 BOLT (3/8-16X6.25-IN)2
23144718 BOLT (1/2-13X6.5-IN)8
32186429 PLUG AS2
9S8003PLUG (1/2-20-THD)1
2147567SEAL-O-RING1
5M289410 WASHER-HARD (10.2X18.5X2.5-MM THK)28
5P824512 WASHER-HARD (13.5X25.5X3-MM THK)8
307267113 PLUG AS2
9S8002PLUG (7/16-20-THD)1
2147566SEAL-O-RING1
183340714 PLUG AS2
9S8004PLUG (9/16-18-THD)1
2147568SEAL-O-RING1
307267315 PLUG AS2
9S8005PLUG (3/4-16-THD)1
2385080SEAL-O-RING1
8S919116 BOLT (3/8-16X4-IN)6
315985920 PLUG AS1
9S8008PLUG (1-1/16-12-THD)1
2385082SEAL-O-RING1
