System And Components
354-8795 SHIELD GP-HEATS/N MHM1-UP
Group No: 354-8795
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6N9533 | 1 SHIELD AS-HEAT | 2 | |
| 3542429 | 2 SHIELD AS-HEAT | 1 | |
| 9F6445 | NUT-WELD (1/4-20-THD) | 3 | |
| 4894570 | 3 SHIELD AS-HEAT | 1 | |
| 4894569 | SHIELD AS-HEAT | 1 | |
| 9F6445 | NUT-WELD (1/4-20-THD) | 3 | |
| 3771052 | 4 SHIELD AS-HEAT | 1 | |
| 3771053 | 5 SHIELD AS-HEAT | 1 | |
| 4950359 | 6 SHIELD AS-HEAT | 1 | |
| 4950357 | 7 SHIELD AS-HEAT | 1 | |
| 1S9169 | 8 BOLT-HIGH TEMPERATURE (3/8-16X0.75-IN) | 12 | |
| 0S1614 | 9 BOLT (1/4-20X0.5-IN) | 4 | |
| 2A0762 | 10 BOLT (1/4-20X0.625-IN) | 6 | |
| 5P0537 | 11 WASHER-HARD (7.2X14.5X2-MM THK) | 4 | |
| 5P4115 | 12 WASHER-HARD (7.2X19X2-MM THK) | 6 | |
| 8T4896 | 13 WASHER-HARD (10.2X18.5X2.5-MM THK) | 12 |
