System And Components
362-1166 CYLINDER BLOCK GPS/N H6C1-UP
Group No: 362-1166
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2W2940 | 1 PLUG (OIL MANIFOLD) | 8 | |
| 7N2047 | 2 DOWEL | 3 | |
| 7N5641 | 3 PLUG-MANIFOLD | 2 | |
| 1977008 | 5 DOWEL | 16 | |
| 3621165 | 6 CYLINDER BLOCK AS | 1 | |
| 1161359 | 8 BEARING-CAMSHAFT | 18 | |
| 2147568 | 10 SEAL-O-RING | 6 | |
| 4N0683 | 11 DOWEL | 2 | |
| 5F9657 | 12 SEAL-O-RING | 4 | |
| 6V3348 | 16 SEAL-O-RING | 8 | |
| 7N2044 | 17 DOWEL | 2 | |
| 7X4805 | 18 SEAL-O-RING | 3 | |
| 7X7731 | 19 PLUG-PIPE (3/4-14-THD) | 2 | |
| 8T0099 | 20 DOWEL | 32 | |
| 8T6762 | 21 PLUG-PIPE (1/2-14-THD) | 4 | |
| 8T6763 | 22 PLUG-PIPE (1/4-18-THD) | 26 | |
| 9S4191 | 23 PLUG (9/16-18-THD) | 6 | |
| 8N8056 | 24 COVER | 2 | |
| 0S1595 | 25 BOLT (1/2-13X1.25-IN) | 2 | |
| 1A2029 | 26 BOLT (3/8-16X1.125-IN) | 2 | |
| 5M2894 | 27 WASHER-HARD (10.2X18.5X2.5-MM THK) | 2 | |
| 5P8210 | 28 SEAL-O-RING | 2 | |
| 5P8245 | 29 WASHER-HARD (13.5X25.5X3-MM THK) | 2 |
