System And Components
418-9804 CYLINDER HEAD ASS/N H6C1-133
Group No: 418-9804
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3661338 | 1 GUIDE-VALVE (EXHAUST) | 2 | |
| 3661339 | GUIDE-VALVE (0.25-MM OS, EXHAUST) | ||
| 3661340 | GUIDE-VALVE (0.51-MM OS, EXHAUST) | ||
| 1916766 | 2 GUIDE-VALVE (INLET) | 2 | |
| 2061544 | GUIDE-VALVE (0.25-MM OS, INLET) | ||
| 2061545 | GUIDE-VALVE (0.508-MM OS, INLET) | ||
| 4236982 | 3 GASKET | 1 | |
| 2088776 | 4 PLUG-CUP | 1 | |
| 2197000 | 5 SEAL-O-RING | 1 | |
| 5475249 | 6 SCREEN | 1 | |
| 4532319 | 7 ADAPTER | 1 | |
| 3087100 | 9 INSERT-VALVE SEAT (STANDARD) | 4 | |
| 3223659 | INSERT-VALVE SEAT (0.25-MM OS) | ||
| 3223660 | INSERT-VALVE SEAT (0.51-MM OS) | ||
| 3B0623 | 10 PLUG-CUP (25.73-MM OD) | 5 | |
| 3B0645 | 11 PLUG-CUP (32.08-MM OD) | 3 | |
| 2147566 | 12 SEAL-O-RING | 2 | |
| 6V7604 | 13 PLUG-CUP | 4 | |
| 7F9090 | 14 SCREW-DRIVE (NO 8X3/8-IN) | 3 | |
| 7J0204 | 15 SEAL-O-RING | 6 | |
| 9S8002 | 16 PLUG (7/16-20-THD) | 2 | |
| 9S8007 | 17 PLUG (3/8-24-THD) | 6 | |
| 4189802 | 18 CYLINDER HEAD | 1 |
