System And Components
377-2399 LINES GP-TURBOCHARGER WATERS/N H6C1-UP
Group No: 377-2399
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7N3368 | 1 GASKET | 1 | |
| 4609881 | 2 HOSE AS | 1 | |
| 3552930 | 3 PLATE | 1 | |
| 3552933 | 4 BRACKET | 1 | |
| 3586212 | 5 HOSE AS | 1 | |
| 3586215 | 6 BRACKET | 1 | |
| 3592890 | 7 PLUG AS | 2 | |
| 1559646 | SEAL | 1 | |
| 3676005 | PLUG | 1 | |
| 3592891 | 8 CONNECTOR AS | 2 | |
| 5K9090 | SEAL-O-RING | 1 | |
| 1559646 | SEAL | 1 | |
| 3675998 | CONNECTOR | 1 | |
| 3603680 | 9 PLUG (3/4-16-THD) | 2 | |
| 3960633 | 10 HOSE AS | 1 | |
| 0S1588 | 11 BOLT (3/8-16X1.25-IN) | 1 | |
| 6V8675 | 12 BOLT (M12X1.75X35-MM) | 1 | |
| 0S1621 | 13 BOLT (1/2-13X1-IN) | 1 | |
| 6V7359 | 14 GROMMET (25-MM ID, 37-MM OD) | 1 | |
| 1645615 | 15 ELBOW AS | 1 | |
| 4K1388 | SEAL-O-RING | 1 | |
| 5K9090 | SEAL-O-RING | 1 | |
| 8T8986 | ELBOW | 1 | |
| 1808424 | 16 SEAL-O-RING | 2 | |
| 6V8149 | 17 NUT (M12X1.75-THD) | 1 | |
| 3180820 | 18 GROMMET | 1 | |
| 3E2333 | 19 ELBOW | 1 | |
| 3K0360 | 20 SEAL-O-RING | 2 | |
| 4J5907 | 21 BOLT (3/8-16X1.375-IN) | 3 | |
| 5K9090 | 22 SEAL-O-RING | 3 | |
| 5M2894 | 23 WASHER-HARD (10.2X18.5X2.5-MM THK) | 2 | |
| 5P8245 | 24 WASHER-HARD (13.5X25.5X3-MM THK) | 3 | |
| 5P8247 | 25 WASHER-HARD (17X32X3.5-MM THK) | 1 | |
| 6D7128 | 26 SEAL-O-RING | 2 | |
| 6V3250 | 27 SEAL-O-RING | 1 | |
| 6V5064 | 28 SEAL-O-RING | 2 | |
| 6V8557 | 29 NUT-FACE SEAL (1-7/16-12-THD) | 1 | |
| 6V8781 | 30 TEE | 1 | |
| 6V8944 | 31 REDUCER | 1 | |
| 6V9008 | 32 ELBOW (90-DEG) | 1 | |
| 6V9829 | 33 CAP (ORFS) | 1 | |
| 6V9840 | 34 TEE-SWIVEL | 1 | |
| 7S3916 | 35 CLIP (TAB) | 1 | |
| 7S3919 | 36 CLIP (SLOT) | 1 | |
| 8S2331 | 37 BOLT-12 POINT HEAD (5/8-11X2-IN) | 1 | |
| 8T6762 | 38 PLUG-PIPE (1/2-14-THD) | 1 | |
| 5P7464 | 39 CLIP (SLOT) | 1 | |
| 9S4181 | 40 PLUG (1-5/16-12-THD) | 1 | |
| 9S8752 | 41 NUT-FULL (3/8-16-THD) | 1 | |
| 5P7465 | 42 CLIP (TAB) | 1 |
