486-0431 DOOR GP-CAB -LHS/N 6S61-UP; 7P61-UP

Group No: 486-0431

Part Number	Part Name	Qty
3S2093	1 STRAP-CABLE	4
6C9003	2 STOP	1
8T5400	3 CONNECTOR	1
1258175	4 BLADE AS-WIPER (450-MM)(DOOR, LH)	1
4695745	5 VALVE-CHECK	1
2187119	6 GASKET	1
2621998	7 ARM GP-WINDOW WIPER (DOOR, LH)	1
3059192	NOZZLE AS-WASHER	1
2669306	8 STRIKER AS	1
2814002	9 PLUG	1
1333234	10 SEAL (425-CM)
2870548	11 STICKER-DOOR SEAL (BLACK)	1
3044243	12 MOTOR GP-WINDOW WIPER (DOOR, LH)	1
3366672	13 HANDLE AS (PULL)	1
5172463	14 WINDOW-DOOR (LH)	1
3433572	15 FRAME AS-DOOR	1
8T3597	NUT-WELD (M12X1.75-THD)	6
3433586	16 COVER-LATCH (LH)	1
3433590	17 LATCH AS (LH)	1
4853308	18 HINGE AS	2
4536825	WASHER (10.2X20X2-MM THK)	4
8T3597	NUT-WELD (M12X1.75-THD)	3
4897906	19 HARNESS AS-WINDOW WIPER	1
1313540	20 LOCKNUT (M8X1.25-THD)	2
3175316	21 GROMMET	1
3208448	22 CAP-NUT	2
3398938	23 CLIP (LOOP)	2
3E8020	24 SCREW-TRUSS HEAD (M6X1X25-MM)	4
4D0012	25 GROMMET	1
7X0613	26 WASHER-HARD (8.8X25.5X5-MM THK)	2
3445674	27 NUT (M8X1.25-THD)	1
5P1076	28 WASHER-HARD (13.5X30X4-MM THK)	12
5P8439	29 GROMMET	1
8T4139	30 BOLT (M12X1.75X30-MM)	6
8T4183	31 BOLT (M12X1.75X40-MM)	6
8T4224	32 WASHER-HARD (8.8X16X2-MM THK)	2
9D8508	33 GROMMET	1
9X2045	34 SCREW-TRUSS HEAD (M6X1X20-MM)	5
1440195	35 HOSE (97-CM)
1440195	35A HOSE (36-CM)
7K1181	36 STRAP-CABLE	1
9X2038	37 WASHER (7X19X2-MM THK)	2
1409921	38 INSERT-THREADED	4
2239818	39 FILM-INSTRUCTION (WINDOW CLEANING, READ OMM)	1
