System And Components
484-7986 DOOR GP-CAB -LHS/N MP71-UP; ZLJ1-UP
Group No: 484-7986
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3S2093 | 1 STRAP-CABLE | 4 | |
| 6C9003 | 2 STOP | 1 | |
| 8T5400 | 3 CONNECTOR | 1 | |
| 1258175 | 4 BLADE AS-WIPER (450-MM)(DOOR, LH) | 1 | |
| 4695745 | 5 VALVE-CHECK | 1 | |
| 2187119 | 6 GASKET | 1 | |
| 2621998 | 7 ARM GP-WINDOW WIPER (DOOR, LH) | 1 | |
| 3059192 | NOZZLE AS-WASHER | 1 | |
| 2669306 | 8 STRIKER AS | 1 | |
| 2814002 | 9 PLUG | 1 | |
| 1333234 | 10 SEAL (425-CM) | ||
| 2870548 | 11 STICKER-DOOR SEAL (LH) | 1 | |
| 3044243 | 12 MOTOR GP-WINDOW WIPER (DOOR, LH) | 1 | |
| 3366672 | 13 HANDLE AS (PULL) | 1 | |
| 3433556 | 14 WINDOW-DOOR (LH) | 1 | |
| 3433572 | 15 FRAME AS-DOOR | 1 | |
| 3433586 | 16 COVER-LATCH (LH) | 1 | |
| 3433590 | 17 LATCH AS (LH) | 1 | |
| 4853308 | 18 HINGE AS | 2 | |
| 4897906 | 19 HARNESS AS-WINDOW WIPER | 1 | |
| 1313540 | 20 LOCKNUT (M8X1.25-THD) | 2 | |
| 3175316 | 21 GROMMET | 1 | |
| 3208448 | 22 CAP-NUT | 2 | |
| 3398938 | 23 CLIP (LOOP) | 2 | |
| 3E8020 | 24 SCREW-TRUSS HEAD (M6X1X25-MM) | 4 | |
| 4D0012 | 25 GROMMET | 1 | |
| 7X0613 | 26 WASHER-HARD (8.8X25.5X5-MM THK) | 2 | |
| 3445674 | 27 NUT (M8X1.25-THD) | 1 | |
| 5P1076 | 28 WASHER-HARD (13.5X30X4-MM THK) | 12 | |
| 5P8439 | 29 GROMMET | 1 | |
| 8T4139 | 30 BOLT (M12X1.75X30-MM) | 6 | |
| 8T4183 | 31 BOLT (M12X1.75X40-MM) | 6 | |
| 8T4224 | 32 WASHER-HARD (8.8X16X2-MM THK) | 2 | |
| 9D8508 | 33 GROMMET | 1 | |
| 9X2045 | 34 SCREW-TRUSS HEAD (M6X1X20-MM) | 5 | |
| 1440195 | 35 HOSE (36-CM) | ||
| 1440195 | 35A HOSE (97-CM) | ||
| 7K1181 | 36 STRAP-CABLE | 1 | |
| 9X2038 | 37 WASHER (7X19X2-MM THK) | 2 | |
| 1409921 | 38 INSERT-THREADED | 4 |
