System And Components
486-0430 DOOR GP-CAB -RHS/N MP71-UP; ZLJ1-UP
Group No: 486-0430
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3S2093 | 1 STRAP-CABLE | 4 | |
| 6C9003 | 2 STOP | 1 | |
| 8T5400 | 3 CONNECTOR | 1 | |
| 1258175 | 4 BLADE AS-WIPER (450-MM)(DOOR, RH) | 1 | |
| 2187119 | 5 GASKET | 1 | |
| 2621997 | 6 ARM GP-WINDOW WIPER (DOOR, RH) | 1 | |
| 3059192 | NOZZLE AS-WASHER | 1 | |
| 2669307 | 7 STRIKER AS (RH) | 1 | |
| 2814002 | 8 PLUG | 1 | |
| 1333234 | 9 SEAL (425-CM) | ||
| 2870548 | 10 STICKER-DOOR SEAL | 1 | |
| 3044244 | 11 MOTOR GP-WINDOW WIPER (DOOR, RH) | 1 | |
| 3366672 | 12 HANDLE AS (PULL) | 1 | |
| 5172462 | 13 WINDOW-DOOR (RH) | 1 | |
| 3433571 | 14 FRAME AS-DOOR | 1 | |
| 3433585 | 15 COVER-LATCH (RH) | 1 | |
| 3433589 | 16 LATCH AS (RH) | 1 | |
| 4853308 | 17 HINGE AS | 2 | |
| 4897905 | 18 HARNESS AS-WINDOW WIPER (RH) | 1 | |
| 1313540 | 19 LOCKNUT (M8X1.25-THD) | 2 | |
| 3175316 | 20 GROMMET | 1 | |
| 3208448 | 21 CAP-NUT | 2 | |
| 3398938 | 22 CLIP (LOOP) | 2 | |
| 3E8020 | 23 SCREW-TRUSS HEAD (M6X1X25-MM) | 4 | |
| 4D0012 | 24 GROMMET | 1 | |
| 7X0613 | 25 WASHER-HARD (8.8X25.5X5-MM THK) | 2 | |
| 3445674 | 26 NUT (M8X1.25-THD) | 1 | |
| 5P1076 | 27 WASHER-HARD (13.5X30X4-MM THK) | 12 | |
| 5P8439 | 28 GROMMET | 1 | |
| 8T4139 | 29 BOLT (M12X1.75X30-MM) | 6 | |
| 8T4183 | 30 BOLT (M12X1.75X40-MM) | 6 | |
| 8T4224 | 31 WASHER-HARD (8.8X16X2-MM THK) | 2 | |
| 9D8508 | 32 GROMMET | 1 | |
| 9X2045 | 33 SCREW-TRUSS HEAD (M6X1X20-MM) | 5 | |
| 1440195 | 34 HOSE (30-CM) | ||
| 1440195 | 34A HOSE (36-CM) | ||
| 1440195 | 34B HOSE (91-CM) | ||
| 7K1181 | 35 STRAP-CABLE | 1 | |
| 9X2038 | 36 WASHER (7X19X2-MM THK) | 2 | |
| 1409921 | 37 INSERT-THREADED | 4 | |
| 4695745 | 38 VALVE-CHECK | 1 | |
| 2239818 | 39 FILM-INSTRUCTION (WINDOW CLEANING, READ OMM) | 1 |
