515-2043 DOOR GP-CAB -RHS/N MP71-UP

Group No: 515-2043
Part NumberPart NameQty
9X20451 SCREW-TRUSS HEAD (M6X1X20-MM)5
3S20932 STRAP-CABLE3
8T54003 CONNECTOR1
12581754 BLADE AS-WIPER (450-MM)(DOOR, RH)1
21871195 GASKET1
26219976 ARM GP-WINDOW WIPER (DOOR, RH)1
3059192NOZZLE AS-WASHER1
28140027 PLUG1
13332348 SEAL (425-CM)
28705489 STICKER-DOOR SEAL (RH)1
304424410 MOTOR GP-WINDOW WIPER (DOOR, RH)1
336667211 HANDLE AS (PULL)1
340727012 STRIKER AS (RH)1
343355513 WINDOW-DOOR (RH)1
343357114 FRAME AS-DOOR1
343358515 COVER-LATCH (RH)1
343358916 LATCH AS (RH)1
489790517 HARNESS AS-WINDOW WIPER (RH)1
515204518 HINGE AS2
131354019 LOCKNUT (M8X1.25-THD)2
317531620 GROMMET1
320844821 CAP-NUT2
339893822 CLIP (LOOP)2
3E802023 SCREW-TRUSS HEAD (M6X1X25-MM)4
4D001224 GROMMET1
4I487225 SPACER (8.6X18X5-MM THK)2
5P107626 WASHER-HARD (13.5X30X4-MM THK)12
5P843927 GROMMET1
8T413928 BOLT (M12X1.75X30-MM)6
8T418329 BOLT (M12X1.75X40-MM)6
8T422430 WASHER-HARD (8.8X16X2-MM THK)2
9D850831 GROMMET1
144019533 HOSE (26-CM)
144019533A HOSE (121-CM)
