Assembly
100%

515-2044 DOOR GP-CAB -LHS/N MP71-UP

Group No: 515-2044
Part NumberPart NameQty
9X20451 SCREW-TRUSS HEAD (M6X1X20-MM)5
3S20932 STRAP-CABLE3
8T54003 CONNECTOR1
12581754 BLADE AS-WIPER (450-MM)(DOOR, LH)1
20425815 VALVE AS-CHECK1
21871196 GASKET1
26219987 ARM GP-WINDOW WIPER (DOOR, LH)1
3059192NOZZLE AS-WASHER1
28140028 PLUG1
13332349 SEAL (425-CM)
287054810 STICKER-DOOR SEAL (LH)1
304424311 MOTOR GP-WINDOW WIPER (DOOR, LH)1
336667212 HANDLE AS (PULL)1
340727113 STRIKER AS (LH)1
343355614 WINDOW-DOOR (LH)1
343357215 FRAME AS-DOOR1
343358616 COVER-LATCH (LH)1
343359017 LATCH AS (LH)1
489790618 HARNESS AS-WINDOW WIPER1
515204519 HINGE AS2
131354020 LOCKNUT (M8X1.25-THD)2
317531621 GROMMET1
320844822 CAP-NUT2
339893823 CLIP (LOOP)2
3E802024 SCREW-TRUSS HEAD (M6X1X25-MM)4
4D001225 GROMMET1
4I487226 SPACER (8.6X18X5-MM THK)2
5P107627 WASHER-HARD (13.5X30X4-MM THK)12
5P843928 GROMMET1
8T413929 BOLT (M12X1.75X30-MM)6
8T418330 BOLT (M12X1.75X40-MM)6
8T422431 WASHER-HARD (8.8X16X2-MM THK)2
9D850832 GROMMET1
144019534 HOSE (26-CM)
144019534A HOSE (97-CM)
