System And Components
347-5024 LINES GP-WATERS/N TW41-UP
Group No: 347-5024
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3718949 | 1 HOSE (19-CM EACH) | ||
| 6N9590 | 2 PLUG-DRAIN (RADIATOR) | 1 | |
| 6V0675 | 3 ELBOW | 1 | |
| 7E9171 | 4 ADAPTER-PLUG | 1 | |
| 0617208 | 5 CLAMP-TUBE | 1 | |
| 1173335 | 6 BRACKET AS | 1 | |
| 2446626 | 7 HOSE | 2 | |
| 3399660 | 8 ELBOW | 1 | |
| 4331423 | 9 TUBE AS | 1 | |
| 3756929 | 10 TUBE | 1 | |
| 4433501 | 11 TUBE | 1 | |
| 3756931 | 12 BRACKET | 1 | |
| 3783651 | 13 HOSE AS | 1 | |
| 4528551 | 14 HOSE AS | 1 | |
| 1336934 | 15 SPACER (11X20X25-MM THK) | 1 | |
| 3650581 | 16 CONNECTOR AS | 1 | |
| 6V6609 | SEAL-O-RING | 1 | |
| 1808424 | SEAL-O-RING | 1 | |
| 6V8639 | CONNECTOR | 1 | |
| 3664669 | 18 ELBOW AS | 2 | |
| 6V3250 | SEAL-O-RING | 1 | |
| 1808424 | SEAL-O-RING | 1 | |
| 8T6876 | ELBOW | 1 | |
| 2094573 | 19 CLAMP-T BOLT | 4 | |
| 2094580 | 20 CLAMP-T BOLT | 4 | |
| 3664676 | 21 CONNECTOR AS | 1 | |
| 6V9873 | CONNECTOR | 1 | |
| 6V3250 | SEAL-O-RING | 1 | |
| 1808424 | SEAL-O-RING | 1 | |
| 3269712 | 22 SPACER (11.4X25.4X35-MM THK) | 2 | |
| 3S8665 | 23 CLIP (LOOP) | 2 | |
| 8T4121 | 24 WASHER-HARD (11X21X2.5-MM THK) | 7 | |
| 8T4136 | 25 BOLT (M10X1.5X25-MM) | 2 | |
| 8T4137 | 26 BOLT (M10X1.5X20-MM) | 1 | |
| 8T4182 | 27 BOLT (M10X1.5X45-MM) | 1 | |
| 8T4195 | 28 BOLT (M10X1.5X30-MM) | 1 | |
| 8T4896 | 29 WASHER-HARD (10.2X18.5X2.5-MM THK) | 2 | |
| 8T6466 | 30 BOLT (M10X1.5X60-MM) | 2 | |
| 8T9377 | 31 BOLT (3/8-16X2.25-IN) | 2 | |
| 5P0765 | 32 HOSE (11-CM) | ||
| 8M7066 | 33 GASKET | 1 | |
| 2S3440 | 34 CLAMP-HOSE | 1 | |
| 2164983 | 35 CLAMP-T BOLT | 2 | |
| 2006345 | 36 SADDLE-MOUNTING (DUAL SWIVEL) | 1 | |
| 2042281 | 37 STRAP-CABLE | 2 |
