System And Components
573-7160 LINES GP-HYDRAULICS/N DN71-UP
Group No: 573-7160
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1065125 | 1 CLIP (SLOT) | 1 | |
| 1065126 | 2 CLIP (TAB) | 1 | |
| 1488320 | 3 CONNECTOR AS | 1 | |
| 4J5477 | SEAL-O-RING | 1 | |
| 8C6865 | CONNECTOR | 1 | |
| 1488351 | 4 ELBOW AS | 1 | |
| 4J5477 | SEAL-O-RING | 1 | |
| 6V9849 | ELBOW | 1 | |
| 1488389 | 5 ELBOW AS | 1 | |
| 4J5477 | SEAL-O-RING | 1 | |
| 7X0492 | ELBOW | 1 | |
| 1488455 | 6 UNION AS | 2 | |
| 6V8997 | UNION | 1 | |
| 6V9746 | SEAL-O-RING | 2 | |
| 1504049 | 7 ELBOW AS | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 7M8485 | SEAL-O-RING | 1 | |
| 8T4149 | ELBOW | 1 | |
| 1608708 | 8 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 1646859 | 9 UNION AS | 4 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 6V9353 | UNION | 1 | |
| 7J9108 | SEAL-O-RING | 1 | |
| 1932120 | 10 GROMMET | 1 | |
| 2721882 | 11 STUD-TAPERLOCK (M12X1.75X80-MM) | 1 | |
| 2875701 | 12 BOLT (M20X2.5X50-MM) | 3 | |
| 2884402 | 13 STUD-TAPERLOCK (M10X1.5X60-MM) | 1 | |
| 3293356 | 14 NUT (M12X1.75-THD) | 1 | |
| 3398936 | 15 CLIP (LOOP) | 3 | |
| 3445675 | 16 NUT (M10X1.5-THD) | 1 | |
| 5667079 | 17 HOSE AS | 1 | |
| 5667082 | 18 HOSE AS | 1 | |
| 5667087 | 19 HOSE AS | 1 | |
| 5667095 | 20 TUBE AS | 1 | |
| 5667096 | 21 TUBE AS | 1 | |
| 5667097 | 22 TUBE AS | 1 | |
| 5667099 | 23 TUBE AS | 1 | |
| 5667100 | 24 TUBE AS | 1 | |
| 5667101 | 25 TUBE AS | 1 | |
| 5668528 | 26 PLATE AS | 1 | |
| 5668582 | 27 PLATE | 1 | |
| 5737171 | 28 HOSE AS | 1 | |
| 5737161 | 29 PLATE | 1 | |
| 5737162 | 30 HOSE AS | 1 | |
| 5737163 | 31 HOSE AS | 1 | |
| 5737164 | 32 HOSE AS | 1 | |
| 5737165 | 33 HOSE AS | 1 | |
| 5737166 | 34 HOSE AS | 1 | |
| 5737167 | 35 HOSE AS | 1 | |
| 5737168 | 36 HOSE AS | 1 | |
| 5737169 | 37 HOSE AS | 1 | |
| 5737170 | 38 HOSE AS | 1 | |
| 5737172 | 39 HOSE AS | 1 | |
| 5737173 | 40 HOSE AS | 1 | |
| 5737174 | 41 HOSE AS | 1 | |
| 5737175 | 42 HOSE AS | 1 | |
| 5737176 | 43 HOSE AS | 1 | |
| 1P3704 | 44 SEAL-RECTANGULAR | 4 | |
| 1P4584 | 45 FLANGE-HALF | 8 | |
| 1P5767 | 46 FLANGE-HALF | 20 | |
| 2P1293 | 47 LOCKNUT (1-3/16-12-THD) | 2 | |
| 5P1076 | 48 WASHER-HARD (13.5X30X4-MM THK) | 1 | |
| 5P7468 | 49 CLIP (SLOT) | 2 | |
| 5P7469 | 50 CLIP (TAB) | 2 | |
| 5P7470 | 51 CLIP (SLOT) | 4 | |
| 5P7471 | 52 CLIP (TAB) | 4 | |
| 5P8182 | 53 GROMMET (46-MM ID) | 4 | |
| 6J2680 | 54 SEAL-O-RING | 2 | |
| 6V1867 | 55 CLIP (SLOT) | 1 | |
| 6V1868 | 56 CLIP (TAB) | 1 | |
| 6V1874 | 57 GROMMET (31-MM ID) | 2 | |
| 6V9169 | 58 NUT (13/16-16-THD) | 4 | |
| 7X7729 | 59 WASHER (11X25X3-MM THK) | 3 | |
| 8T4121 | 60 WASHER-HARD (11X21X2.5-MM THK) | 6 | |
| 8T4123 | 61 WASHER (22X35X3.5-MM THK) | 3 | |
| 8T4139 | 62 BOLT (M12X1.75X30-MM) | 1 | |
| 8T4136 | 63 BOLT (M10X1.5X25-MM) | 4 | |
| 8T4184 | 64 BOLT (M12X1.75X45-MM) | 24 | |
| 8T4194 | 65 BOLT (M12X1.75X50-MM) | 9 | |
| 8T4195 | 66 BOLT (M10X1.5X30-MM) | 2 | |
| 8T4196 | 67 BOLT (M10X1.5X35-MM) | 2 | |
| 8T4223 | 68 WASHER-HARD (13.5X25.5X3-MM THK) | 38 | |
| 8T4910 | 69 BOLT (M12X1.75X60-MM) | 4 | |
| 8T7529 | 70 CLIP | 1 | |
| 9M4995 | 71 CLIP | 1 | |
| 9X7456 | 72 GROMMET | 1 |
