System And Components
481-2031 LINES GP-AIR -VARIABLE PITCH FANS/N GMS1-UP
Group No: 481-2031
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3S2093 | 1 STRAP-CABLE | 1 | |
| 4H6112 | 2 BREATHER (AIR) | 1 | |
| 7K1181 | 3 STRAP-CABLE | 4 | |
| 1488368 | 4 ELBOW AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 4J5477 | SEAL-O-RING | 1 | |
| 6V8627 | ELBOW | 1 | |
| 1882461 | 5 VALVE GP-SOLENOID (VARIABLE PITCH FAN) | 1 | |
| 3779564 | 6 ELBOW AS | 3 | |
| 4J5477 | SEAL-O-RING | 1 | |
| 3779563 | ADAPTER-ELBOW | 1 | |
| 3779581 | 7 ELBOW AS | 1 | |
| 4J5477 | SEAL-O-RING | 1 | |
| 3779577 | ADAPTER-ELBOW | 1 | |
| 3880786 | 8 HOSE AS | 1 | |
| 3896081 | 9 PUMP & MTG GP-HYDRAULIC FAN (VARIABLE PITCH FAN AIR PUMP) | 1 | |
| 4812032 | 10 HOSE AS | 1 | |
| 4827489 | 11 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 2 | |
| 9X2032 | NUT-WELD (M4X0.7-THD) | 2 | |
| 4840294 | 12 HOSE AS | 1 | |
| 1240174 | 13 CLIP (LOOP) | 6 | |
| 1305300 | 14 CLIP | 1 | |
| 1325789 | 15 CLIP (LADDER) | 1 | |
| 1336934 | 16 SPACER (11X20X25-MM THK) | 1 | |
| 1705632 | 17 BOLT (M4X0.7X16-MM) | 2 | |
| 1P4278 | 18 CLAMP-HOSE | 1 | |
| 2062423 | 19 SADDLE-MOUNTING | 2 | |
| 2118071 | 20 CAP-PROTECTIVE | 1 | |
| 3445675 | 21 NUT (M10X1.5-THD) | 1 | |
| 4D9517 | 22 CLIP | 1 | |
| 5F9757 | 23 GROMMET | 1 | |
| 7J8611 | 24 ELBOW-PIPE | 1 | |
| 7X0579 | 25 WASHER-HARD (8.8X25.5X2-MM THK) | 6 | |
| 7X7729 | 26 WASHER (11X25X3-MM THK) | 2 | |
| 8M2770 | 27 CLIP (LOOP) | 3 | |
| 8T3016 | 28 WASHER (5.3X10X1-MM THK) | 2 | |
| 8T4121 | 29 WASHER-HARD (11X21X2.5-MM THK) | 11 | |
| 8T4136 | 30 BOLT (M10X1.5X25-MM) | 4 | |
| 8T4137 | 31 BOLT (M10X1.5X20-MM) | 4 | |
| 8T4195 | 32 BOLT (M10X1.5X30-MM) | 3 | |
| 8T6466 | 33 BOLT (M10X1.5X60-MM) | 1 | |
| 8T6912 | 34 BOLT (M8X1.25X50-MM) | 3 | |
| 7I7439 | 35 GUARD-HOSE (40.8-CM) | ||
| 7I7439 | 35A GUARD-HOSE (29.5-CM) |
