System And Components
502-6446 DOOR GP-CABS/N NHL1-UP
Group No: 502-6446
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6V7636 | 1 PIN AS-SPRING | 1 | |
| 8T4244 | 2 NUT (M12X1.75-THD) | 1 | |
| 9X6155 | 3 BOLT-SOCKET HEAD (M6X1X16.7-MM) | 1 | |
| 0909555 | 4 CLIP | 2 | |
| 1785572 | 5 SPACER-SPECIAL | 4 | |
| 2061667 | 6 CLIP (TRIM) | 6 | |
| 2149186 | 7 BUTTON | 12 | |
| 2521862 | 8 HANDLE AS-PULL | 1 | |
| 2521863 | 9 GASKET | 1 | |
| 2692890 | 10 CLEVIS | 1 | |
| 2692892 | 11 PIN | 1 | |
| 5055964 | 12 SPACER-SPECIAL | 1 | |
| 3026392 | 13 PLUG | 1 | |
| 3716089 | 14 WINDOW GP-DOOR | 1 | |
| 3719511 | 15 HINGE AS | 2 | |
| 3725042 | 15A BUSHING | 2 | |
| 3719522 | 16 BRACKET | 1 | |
| 3727280 | 17 LATCH AS | 1 | |
| 3743585 | 18 END-YOKE ROD | 1 | |
| 3743586 | 19 PIN AS-SPRING | 1 | |
| 3770647 | 20 BRACKET | 1 | |
| 3833563 | 21 BELLCRANK AS | 1 | |
| 4180207 | 22 ROD | 1 | |
| 4180210 | 23 BUSHING | 1 | |
| 4265412 | 24 SEAL AS | 1 | |
| 4262831 | SEAL-DOOR | 1 | |
| 4265409 | PIN | 48 | |
| 4361542 | 25 PLUG-BUTTON | 6 | |
| 4390688 | 26 STRIKER AS | 1 | |
| 4460368 | 27 PLATE AS | 1 | |
| 4540658 | 28 SPRING-GAS (CAB DOOR) | 1 | |
| 4607427 | 29 COVER-DOOR | 1 | |
| 4626225 | 30 GLASS | 1 | |
| 4655966 | 31 DOOR AS-CAB (LH) | 1 | |
| 4655987 | 32 TUBE AS | 1 | |
| 4747583 | 33 HANDLE AS | 1 | |
| 4758095 | 34 PLATE AS | 2 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 2 | |
| 5013976 | 35 BRACKET AS | 1 | |
| 8T3597 | NUT-WELD (M12X1.75-THD) | 1 | |
| 4869155 | 36 BUMPER AS | 1 | |
| 1146658 | 37 WASHER (6.5X17X1-MM THK) | 5 | |
| 1085471 | 38 CLEVIS | 1 | |
| 1199706 | 39 STUD-BALL | 2 | |
| 1219870 | 40 SCREW-MACHINE (M6X1X40-MM) | 4 | |
| 1272170 | 41 SCREW-TRUSS HEAD (M8X1.25X20-MM) | 10 | |
| 1372255 | 42 BOLT (M8X1.25X8-MM) | 1 | |
| 1950936 | 43 INSERT-THREADED (M6X1-THD) | 1 | |
| 1953699 | 44 NUT (M8X1.25-THD) | 1 | |
| 2425206 | 45 SPACER (6.4X12.5X0.76-MM THK) | 3 | |
| 3220819 | 46 INSERT-THREADED (M10X1.5-THD) | 6 | |
| 3445673 | 47 NUT (M6X1-THD) | 4 | |
| 3463811 | 48 NUT-SQUARE | 1 | |
| 3E4353 | 49 WASHER-HARD (11X25X3-MM THK) | 5 | |
| 1728591 | 50 NUT-CLIP (M6X1-THD) | 3 | |
| 5C9553 | 51 BOLT (M6X1X16-MM) | 1 | |
| 5P4116 | 52 WASHER-HARD (8.8X20.5X2-MM THK) | 11 | |
| 6V5839 | 53 WASHER (11X21X2.5-MM THK) | 3 | |
| 8T4138 | 54 BOLT (M6X1X20-MM) | 2 | |
| 8T6902 | 55 CLIP | 1 | |
| 9X2038 | 56 WASHER (7X19X2-MM THK) | 1 | |
| 9X2039 | 57 SCREW-TRUSS HEAD (M10X1.5X35-MM) | 8 | |
| 9X2040 | 58 SCREW-TRUSS HEAD (M10X1.5X25-MM) | 6 | |
| 9X2041 | 59 SCREW-TRUSS HEAD (M10X1.5X20-MM) | 2 | |
| 9X2042 | 60 SCREW-TRUSS HEAD (M6X1X12-MM) | 2 | |
| 9X2044 | 61 SCREW-TRUSS HEAD (M6X1X16-MM) | 3 | |
| 9X6421 | 62 RING-RETAINING | 1 | |
| 9X8256 | 63 WASHER (6.6X12X2-MM THK) | 2 |
