System And Components
295-5122 AFTERCOOLER GP-AIRS/N KD21-UP
Group No: 295-5122
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8D3786 | 1 MOUNTING | 4 | |
| 3493963 | 2 BRACKET | 2 | |
| 3493964 | 3 BRACKET | 1 | |
| 3493965 | 4 BRACKET | 1 | |
| 3526244 | 5 CORE AS-AFTERCOOLER | 1 | |
| 3564829 | 6 PLATE AS | 2 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 2 | |
| 1984777 | 7 WASHER-HARD (11X25X10-MM THK) | 14 | |
| 7X0618 | 8 WASHER-HARD (13.5X40X5-MM THK) | 4 | |
| 8T4182 | 9 BOLT (M10X1.5X45-MM) | 6 | |
| 8T4186 | 10 BOLT (M10X1.5X40-MM) | 8 | |
| 8T4194 | 11 BOLT (M12X1.75X50-MM) | 4 |
