System And Components
344-7798 LINES GP-TURBOCHARGER WATERS/N ENG1-UP
Group No: 344-7798
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3579302 | 1 TUBE AS | 1 | |
| 3579304 | 2 BRACKET AS | 1 | |
| 1F0750 | NUT-WELD (3/8-16-THD) | 1 | |
| 3664693 | 3 ADAPTER AS | 2 | |
| 6V6609 | SEAL-O-RING | 1 | |
| 0308110 | CONNECTOR | 1 | |
| 4595116 | 4 HOSE & TUBE AS | 1 | |
| 1714364 | 5 SPACER (11X19X11.5-MM THK) | 1 | |
| 0S0509 | 6 BOLT (3/8-16X0.75-IN) | 3 | |
| 0S1594 | 7 BOLT (3/8-16X1-IN) | 1 | |
| 1327551 | 8 SPACER (11X19X6-MM THK) | 1 | |
| 1808424 | 9 SEAL-O-RING | 1 | |
| 3491209 | 10 CLIP | 1 | |
| 3510279 | 11 ADAPTER AS | 1 | |
| 5P6944 | ADAPTER | 1 | |
| 6V6609 | SEAL-O-RING | 1 | |
| 4216200 | 12 ELBOW AS | 1 | |
| 4K6297 | ELBOW | 1 | |
| 6V3250 | SEAL-O-RING | 1 | |
| 5D6523 | 13 CLIP | 1 | |
| 5M2894 | 14 WASHER-HARD (10.2X18.5X2.5-MM THK) | 4 | |
| 6V1943 | 15 BOLT-HIGH TEMPERATURE (3/8-16X1.125-IN) | 1 | |
| 9S8752 | 16 NUT-FULL (3/8-16-THD) | 1 | |
| 8M0547 | 17 ELBOW-FLARED (SWIVEL) | 1 | |
| 2H0435 | 18 CLAMP | 2 |
