System And Components
448-0350 INSULATION GP-HEAT -EXHAUST MODULES/N AW41-UP
Group No: 448-0350
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2938668 | 1 BOLT-FLANGE HEAD (M6X1X16-MM) | 45 | |
| 3945033 | 2 SHIELD-HEAT | 1 | |
| 3945040 | 3 SHIELD-HEAT | 1 | |
| 3945042 | 4 BRACKET AS | 1 | |
| 6V9632 | NUT-WELD (M6X1-THD) | 2 | |
| 3945043 | 5 SHIELD-HEAT | 1 | |
| 3945044 | 6 SHIELD-HEAT | 1 | |
| 4480343 | 7 SHIELD-HEAT | 1 | |
| 4480344 | 8 SHIELD-HEAT | 1 | |
| 4480345 | 9 SHIELD-HEAT | 1 | |
| 4480346 | 10 SHIELD-HEAT | 1 | |
| 4480347 | 11 SHIELD-HEAT | 1 | |
| 4480351 | 12 SHIELD-HEAT | 1 | |
| 4480352 | 13 SHIELD-HEAT | 1 | |
| 4480353 | 14 SHIELD-HEAT | 1 | |
| 4480354 | 15 SHIELD-HEAT | 1 | |
| 4480355 | 16 SHIELD-HEAT | 1 | |
| 8T4224 | 17 WASHER-HARD (8.8X16X2-MM THK) | 9 | |
| 3193515 | 18 BOLT-FLANGE HEAD (M6X1X10-MM) | 43 | |
| 8T4908 | 19 BOLT (M8X1.25X25-MM) | 2 | |
| 3585522 | 20 BOLT-FLANGE HEAD (M6X1X25-MM) | 2 |
