System And Components
465-8149 LINES GP-STEERINGS/N AW41-953
Group No: 465-8149
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8T4910 | 1 BOLT (M12X1.75X60-MM) | 2 | |
| 8T5412 | 2 BOLT (M12X1.75X140-MM) | 2 | |
| 4J0520 | 3 SEAL-O-RING | 1 | |
| 5P8444 | 4 GROMMET (37-MM ID) | 3 | |
| 6V0852 | 5 CAP-DUST | 4 | |
| 7X3392 | 6 WASHER-HARD (13.5X22.5X3-MM THK) | 4 | |
| 8C3451 | 7 CAP-DUST (HYDRAULIC OIL) | 1 | |
| 8T5095 | 8 WASHER-PLATED (11X16X2-MM THK) | 4 | |
| 9D7924 | 9 MOUNTING AS | 4 | |
| 1488310 | 10 ADAPTER AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 8T0151 | ADAPTER | 1 | |
| 1488347 | 11 ELBOW AS | 3 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V9007 | ELBOW | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 1488360 | 12 ELBOW AS | 1 | |
| 6V9182 | ELBOW | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 7M8485 | SEAL-O-RING | 1 | |
| 2089756 | 13 HOSE AS | 1 | |
| 2169195 | 14 MANIFOLD | 1 | |
| 2353575 | 15 CONNECTOR AS | 1 | |
| 7J9108 | SEAL-O-RING | 1 | |
| 7M8485 | SEAL-O-RING | 1 | |
| 1387538 | CONNECTOR | 1 | |
| 2386809 | 16 FILTER GP-OIL (STEERING) | 1 | |
| 2431353 | 17 SPACER (11X20X35-MM THK) | 1 | |
| 3664699 | 18 PLUG AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 3603692 | PLUG (9/16-18-THD) | 1 | |
| 4239907 | 19 PLATE AS | 1 | |
| 4340776 | 20 BOLT-12 POINT HEAD (M10X1.5X30-MM) | 4 | |
| 4631255 | 21 HOSE AS | 1 | |
| 4832259 | 22 TUBE AS | 1 | |
| 4832260 | 23 TUBE AS | 1 | |
| 4904754 | 24 HOSE AS | 1 | |
| 5267037 | 25 HOSE AS | 1 | |
| 5267038 | 26 HOSE AS | 1 | |
| 5267039 | 27 HOSE AS | 1 | |
| 5267040 | 28 HOSE AS | 1 | |
| 5267041 | 29 HOSE AS | 1 | |
| 5267042 | 30 HOSE | 1 | |
| 0673045 | 31 CLIP (LOOP) | 1 | |
| 1488315 | 32 CONNECTOR AS | 1 | |
| 2M9780 | SEAL-O-RING | 1 | |
| 6V8642 | CONNECTOR | 1 | |
| 7J9108 | SEAL-O-RING | 1 | |
| 1488322 | 33 CONNECTOR AS | 1 | |
| 2M9780 | SEAL-O-RING | 1 | |
| 6V8640 | CONNECTOR | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 1488335 | 34 CONNECTOR AS | 1 | |
| 5K9090 | SEAL-O-RING | 1 | |
| 6V8635 | CONNECTOR | 1 | |
| 7M8485 | SEAL-O-RING | 1 | |
| 1488341 | 35 CONNECTOR AS | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V8713 | CONNECTOR | 1 | |
| 7J9108 | SEAL-O-RING | 1 | |
| 1488355 | 36 ELBOW AS | 1 | |
| 5K9090 | SEAL-O-RING | 1 | |
| 6V9005 | ELBOW | 1 | |
| 7M8485 | SEAL-O-RING | 1 | |
| 1488393 | 37 ELBOW AS | 1 | |
| 6V9852 | ELBOW (SWIVEL) | 1 | |
| 7J9108 | SEAL-O-RING | 1 | |
| 1488449 | 38 TEE AS-SWIVEL | 2 | |
| 6V9746 | SEAL-O-RING | 2 | |
| 6V9839 | TEE-SWIVEL | 1 | |
| 1504049 | 39 ELBOW AS | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 7M8485 | SEAL-O-RING | 1 | |
| 8T4149 | ELBOW | 1 | |
| 1803998 | 40 STUD (M10X1.5X55-MM) | 2 | |
| 1984778 | 41 WASHER-HARD (13.5X30X12-MM THK) | 1 | |
| 1P3704 | 42 SEAL-RECTANGULAR | 5 | |
| 1P5767 | 43 FLANGE-HALF | 8 | |
| 2659596 | 44 WASHER-HARD (13.5X30X9-MM THK) | 1 | |
| 2721882 | 45 STUD-TAPERLOCK (M12X1.75X80-MM) | 1 | |
| 3293356 | 46 NUT (M12X1.75-THD) | 2 | |
| 3445675 | 47 NUT (M10X1.5-THD) | 2 | |
| 3G8054 | 48 CLIP (TAB) | 1 | |
| 3G8057 | 49 CLIP (SLOT) | 1 | |
| 3J1907 | 50 SEAL-O-RING | 4 | |
| 5499191 | 51 BRACKET | 1 | |
| 5506100 | 52 BLOCK | 1 | |
| 5531212 | 53 BLOCK | 1 | |
| 5531213 | 54 BLOCK | 3 | |
| 5P7468 | 55 CLIP (SLOT) | 1 | |
| 5P7469 | 56 CLIP (TAB) | 1 | |
| 6V0974 | 57 GROMMET | 1 | |
| 6V3965 | 58 FITTING (QUICK DISCONNECT) | 4 | |
| 6V9746 | 59 SEAL-O-RING | 2 | |
| 7X2550 | 60 BOLT (M12X1.75X110-MM) | 3 | |
| 8T1895 | 61 CLIP (SLOT) | 2 | |
| 8T1896 | 62 CLIP (TAB) | 1 | |
| 8T4121 | 63 WASHER-HARD (11X21X2.5-MM THK) | 8 | |
| 8T4184 | 64 BOLT (M12X1.75X45-MM) | 1 | |
| 8T4194 | 65 BOLT (M12X1.75X50-MM) | 17 | |
| 8T4195 | 66 BOLT (M10X1.5X30-MM) | 1 | |
| 8T4223 | 67 WASHER-HARD (13.5X25.5X3-MM THK) | 19 | |
| 8T4226 | 68 WASHER-PLATED (10.5X45X3-MM THK) | 8 | |
| 8T5041 | 69 BOLT (M12X1.75X120-MM) | 1 | |
| 8T6466 | 70 BOLT (M10X1.5X60-MM) | 5 | |
| 8T6703 | 71 CLAMP-HOSE | 2 | |
| 8T7971 | 72 WASHER-HARD (13.5X25.5X5-MM THK) | 4 | |
| 9U6996 | 73 CONNECTOR AS | 2 | |
| 5P1947 | CONNECTOR | 1 | |
| 6K6307 | SEAL-O-RING | 1 | |
| 9Y7595 | 74 SPACER (13X30X14-MM THK) | 2 | |
| 5616314 | 75 BLOCK | 1 | |
| 7S3916 | 76 CLIP (TAB) | 1 |
