System And Components
389-6458 SUPPORT GP-TRANSMISSIONS/N EWX1-UP
Group No: 389-6458
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4828998 | 1 MOUNT AS | 2 | |
| 4828995 | MOUNT AS | 1 | |
| 4828997 | PAD | 1 | |
| 9W6582 | 2 SLEEVE | 6 | |
| 9W9930 | 3 MOUNT AS | 4 | |
| 1736640 | 4 NUT AS | 2 | |
| 3048704 | 5 SUPPORT AS-LOWER | 2 | |
| 1A2223 | DOWEL | 2 | |
| 4778248 | 6 SUPPORT AS | 1 | |
| 1984780 | 7 WASHER-HARD (17.5X32X8-MM THK) | 8 | |
| 7X2488 | 8 BOLT (M20X2.5X160-MM) | 2 | |
| 7X2555 | 9 BOLT (M16X2X80-MM) | 8 | |
| 7X2622 | 10 WASHER (22X115X10-MM THK) | 8 | |
| 8T4123 | 11 WASHER (22X35X3.5-MM THK) | 8 | |
| 8T5439 | 12 WASHER-HARD (21.5X45X6-MM THK) | 8 | |
| 8T6381 | 13 BOLT (M20X2.5X120-MM) | 4 | |
| 8T6430 | 14 BOLT (M20X2.5X50-MM) | 8 |
