480-3874 LINES GP-TURBOCHARGER OILS/N L4G1032-UP

Group No: 480-3874
Part NumberPart NameQty
12754471 SPACER (10.5X20X12-MM THK)4
27412852 MANIFOLD2
28159403 CONNECTOR AS2
8T7494CONNECTOR (STRAIGHT)1
2287092SEAL-O-RING1
2287106SEAL-O-RING1
36122174 HOSE AS4
28159205 CONNECTOR AS4
2270064CONNECTOR1
2287091SEAL-O-RING1
2287105SEAL-O-RING1
46740416 MANIFOLD2
48038327 TUBE AS2
46410438 ADAPTER AS2
6V9007ELBOW1
2287092SEAL-O-RING1
2385082SEAL-O-RING1
48038319 TUBE AS2
501254510 CONNECTOR AS4
8T7490CONNECTOR-TUBE1
2287090SEAL-O-RING1
2287103SEAL-O-RING1
582081411 HOSE AS2
582107612 TUBE AS2
8T189013 CLIP (TAB)10
228709214 SEAL-O-RING2
6V798115 BOLT (M10X1.5X70-MM)4
8T188916 CLIP (SLOT)10
319622517 ELBOW AS4
6V8625ELBOW1
2287090SEAL-O-RING1
2385080SEAL-O-RING1
319622718 ELBOW AS4
6V9851ELBOW1
2287090SEAL-O-RING1
321863219 CONNECTOR AS4
6V8632CONNECTOR1
2287091SEAL-O-RING1
2385080SEAL-O-RING1
332856220 ELBOW AS4
6V9852ELBOW (SWIVEL)1
2287091SEAL-O-RING1
353795321 GROMMET6
353795422 GROMMET4
6V424823 BOLT (M10X1.5X25-MM)6
6V424924 BOLT (M10X1.5X50-MM)4
6V526625 SEAL-O-RING2
6V583926 WASHER (11X21X2.5-MM THK)18
6V382227 BOLT (M10X1.5X35-MM)4
