275-2038 AFTERCOOLER GPS/N LTZ1-UP

Group No: 275-2038
Part NumberPart NameQty
7E91821 SUPPORT2
42568282 CAP2
51393073 AFTERCOOLER GP-AIR2
28816524 STABILIZER AS2
33609245 PLATE1
33609216 PLATE AS2
33609237 PLATE AS2
31618108 PLATE AS2
31619589 PLATE2
319533810 CHANNEL AS2
8T3597NUT-WELD (M12X1.75-THD)18
198477811 WASHER-HARD (13.5X30X12-MM THK)66
5P107612 WASHER-HARD (13.5X30X4-MM THK)22
7X058313 WASHER-HARD (17X45X6-MM THK)8
198477715 WASHER-HARD (11X25X10-MM THK)60
8N725716 MOUNT AS2
9Y763317 BOLT-LOCKING (M12X1.75X50-MM)6
8T418418 BOLT (M12X1.75X45-MM)12
8T417319 BOLT (M16X2X110-MM)8
8T419420 BOLT (M12X1.75X50-MM)12
7X334821 BOLT-LOCKING60
9Y773422 BOLT-LOCKING (M12X1.75X45-MM)48
8T686823 BOLT (M12X1.75X80-MM)10
336092524 PLATE2
465808525 PLATE AS1
465808826 PLATE1
465808927 PLATE2
465809028 CHANNEL AS2
8T3597NUT-WELD (M12X1.75-THD)34
135857529 BOLT AS30
