System And Components
513-9307 AFTERCOOLER GP-AIRS/N LTZ1-UP
Group No: 513-9307
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6I0454 | 1 BOLT (M10X1.5X70-MM) | 22 | |
| 2089295 | 2 BOLT-FLANGE HEAD (M10X1.5X40-MM) | 90 | |
| 5149888 | 3 BUSHING | 22 | |
| 5149886 | 4 CHANNEL | 2 | |
| 5149883 | 5 CHANNEL AS | 2 | |
| 3231735 | 6 CORE AS-AFTERCOOLER | 1 | |
| 3231732 | 7 GASKET | 1 | |
| 3752467 | 8 LOCKNUT-FLANGE (M10X1.5-THD) | 97 | |
| 3B4508 | 9 LOCKWASHER | 12 | |
| 8T4133 | 10 NUT (M10X1.5-THD) | 24 | |
| 3614753 | 11 ROD | 6 | |
| 3231731 | 12 SEAL-O-RING | 1 | |
| 5164059 | 13 SHIM (0.12-MM THK) | 2 | |
| 3614754 | 14 SPACER-TUBE | 6 | |
| 3231737 | 15 TANK AS-BOTTOM | 1 | |
| 4755715 | 16 TANK AS-TOP | 1 | |
| 9X2027 | 17 WASHER (11X18X2-MM THK) | 12 |
