272-3379 AIR CLEANER GPS/N LTZ1-UP

Group No: 272-3379
Part NumberPart NameQty
12436471 SPACER (17X30X20-MM THK)2
27707362 AIR CLEANER GP2
27832633 SUPPORT AS2
46837614 MOUNT AS4
3558941NUT-WELD (M16X2-THD)7
30984295 BRACE AS1
50706586 PLATE AS4
30984327 BRACE AS1
30984358 BRACE AS1
30984279 PLATE2
309844110 PLATE AS-MOUNTING4
338010611 BRACE AS1
0985653END-ROD2
0985747NUT (M16X2-THD)2
5P107612 WASHER-HARD (13.5X30X4-MM THK)32
7X051513 WASHER-HARD (17X35X5-MM THK)34
7X255214 BOLT (M16X2X30-MM)11
7X255415 BOLT (M16X2X70-MM)2
8T413216 NUT (M16X2-THD)6
8T413917 BOLT (M12X1.75X30-MM)32
8T419318 BOLT (M16X2X50-MM)6
8T422319 WASHER-HARD (13.5X25.5X3-MM THK)16
8T477920 BOLT (M16X2X35-MM)4
8T939321 BOLT (5/8-11X1.5-IN)8
9X825722 WASHER (17.5X30X3.5-MM THK)29
8T495623 BOLT (M12X1.75X35-MM)16
7X034524 BOLT (5/8-11X1.75-IN)26
