System And Components
579-9571 HOOD GP-TRUCKS/N LTZ1-UP
Group No: 579-9571
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4516533 | 1 TUBE | 2 | |
| 3T7857 | 2 PLUG-BUTTON | 2 | |
| 1364992 | 3 SPACER (11X20X40-MM THK) | 4 | |
| 2074258 | 4 NUT (M20X1.5-THD) | 1 | |
| 3470984 | 5 PLATE AS | 1 | |
| 8T3597 | NUT-WELD (M12X1.75-THD) | 2 | |
| 3474475 | 6 STRUT AS | 3 | |
| 0950843 | PIN-COTTER | 2 | |
| 0951313 | PIN-CLEVIS | 2 | |
| 3726348 | 7 PLATE AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 14 | |
| 3744839 | 8 PLATE AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 2 | |
| 3744840 | 9 PLATE AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 2 | |
| 4331577 | 10 BRACKET AS | 2 | |
| 8T3597 | NUT-WELD (M12X1.75-THD) | 2 | |
| 4507656 | 11 PLATE | 1 | |
| 4525010 | 12 LATCH AS | 1 | |
| 4525011 | 13 PAWL | 1 | |
| 4582210 | 14 PLATE AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 5 | |
| 4617175 | 15 PLATE AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 2 | |
| 8Y3795 | BOSS (M10X1.5X40-MM) | 1 | |
| 2944550 | BOSS-WELD (M10X1.5X60-MM) | 4 | |
| 5063240 | BOSS AS | 1 | |
| 8Y3925 | BOSS (M10X1.5X30-MM) | 1 | |
| 4617180 | 16 PLATE AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 2 | |
| 4689981 | 17 SUPPORT AS | 1 | |
| 8T3597 | NUT-WELD (M12X1.75-THD) | 4 | |
| 4694243 | 18 PLATE AS | 2 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 6 | |
| 4703093 | 19 PLATE | 1 | |
| 4703095 | 20 PLATE AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 8 | |
| 4703105 | 21 PLATE AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 4 | |
| 4746603 | 22 PLATE AS | 1 | |
| 4746611 | 23 PLATE AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 2 | |
| 4883971 | 24 BOLT AS | 17 | |
| 4883974 | 25 BOLT AS | 78 | |
| 1379402 | 26 WASHER-NYLON (0.53X1.53X0.125-IN THK) | 2 | |
| 1463287 | 27 BOLT-SPECIAL | 1 | |
| 1984778 | 28 WASHER-HARD (13.5X30X12-MM THK) | 18 | |
| 1984780 | 29 WASHER-HARD (17.5X32X8-MM THK) | 16 | |
| 2519567 | 30 NUT (M20X1.5-THD) | 2 | |
| 4617130 | 31 PLATE AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 21 | |
| 4694247 | 32 SUPPORT AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 31 | |
| 8X3178 | PLATE | 3 | |
| 4703099 | 33 SUPPORT AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 9 | |
| 8T3612 | NUT-WELD (M8X1.25-THD) | 4 | |
| 4792171 | 34 BOLT AS | 16 | |
| 5797899 | 35 PLATE | 1 | |
| 5797907 | 36 PANEL AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 19 | |
| 8T3612 | NUT-WELD (M8X1.25-THD) | 7 | |
| 8Y6368 | PAN-MOUNT | 1 | |
| 5799558 | 37 HINGE AS | 1 | |
| 5799572 | 38 PLATE | 1 | |
| 5824122 | 39 PLATE AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 2 | |
| 5824123 | 40 PLATE AS | 1 | |
| 8T4223 | WASHER-HARD (13.5X25.5X3-MM THK) | 1 | |
| 5824124 | 41 PLATE | 1 | |
| 3B4618 | 42 PIN-COTTER | 2 | |
| 4H4641 | 43 PIN | 2 | |
| 5P1076 | 44 WASHER-HARD (13.5X30X4-MM THK) | 2 | |
| 5P4116 | 45 WASHER-HARD (8.8X20.5X2-MM THK) | 4 | |
| 6V7744 | 46 LOCKNUT (M10X1.5-THD) | 1 | |
| 7X2553 | 47 BOLT (M16X2X40-MM) | 8 | |
| 8T0375 | 48 BOLT (M16X2X45-MM) | 8 | |
| 8T4121 | 49 WASHER-HARD (11X21X2.5-MM THK) | 10 | |
| 8T4133 | 50 NUT (M10X1.5-THD) | 2 | |
| 8T4136 | 51 BOLT (M10X1.5X25-MM) | 4 | |
| 8T4172 | 52 BOLT (M10X1.5X80-MM) | 4 | |
| 8T4183 | 53 BOLT (M12X1.75X40-MM) | 12 | |
| 8T4195 | 54 BOLT (M10X1.5X30-MM) | 2 | |
| 8T4223 | 55 WASHER-HARD (13.5X25.5X3-MM THK) | 2 | |
| 8T4224 | 56 WASHER-HARD (8.8X16X2-MM THK) | 4 | |
| 8T4908 | 57 BOLT (M8X1.25X25-MM) | 8 | |
| 8T4956 | 58 BOLT (M12X1.75X35-MM) | 6 | |
| 5P5661 | 59 SEAL (0.1-M EACH) |
