Assembly
100%

478-4070 INSULATION GP-HEATS/N HFE1-UP; TPL1-UP; HLY1-UP

Group No: 478-4070
Part NumberPart NameQty
21410481 SPACER (8.8X16X4-MM THK)2
37832162 BRACKET AS4
38429213 BRACKET AS1
47840534 SHIELD-HEAT1
47840545 SHIELD-HEAT1
47840556 SHIELD-HEAT1
47840567 SHIELD-HEAT1
47840578 SHIELD-HEAT1
47840589 SHIELD-HEAT1
478405910 SHIELD-HEAT1
478406011 SHIELD-HEAT1
478406112 SHIELD-HEAT1
478406213 SHIELD-HEAT1
478406314 SHIELD-HEAT1
478406415 SHIELD-HEAT1
8T686916 BOLT (M8X1.25X60-MM)4
293866817 BOLT-FLANGE HEAD (M6X1X16-MM)2
8T422418 WASHER-HARD (8.8X16X2-MM THK)4
319351519 BOLT-FLANGE HEAD (M6X1X10-MM)61
358552220 BOLT-FLANGE HEAD (M6X1X25-MM)10
