System And Components
501-7001 DRIVE GP-FANS/N ENG1-UP
Group No: 501-7001
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2U8966 | 1 BOLT-SOCKET HEAD (1/2-13X4.25-IN) | 4 | |
| 9F4446 | 2 SEAL-O-RING | 1 | |
| 2249775 | 3 PULLEY AS-IDLER | 1 | |
| 3812511 | 4 BELT TENSIONER | 1 | |
| 4206210 | 5 SUPPORT-FAN | 1 | |
| 5698674 | 6 BELT-SERPENTINE | 1 | |
| 1495268 | 7 STUD-TAPERLOCK (1/2-13X5.75-IN)(TYPE5) | 2 | |
| 1F7958 | 8 NUT-FULL (1/2-13-THD) | 2 | |
| 3101945 | 9 STUD-TAPERLOCK (M12X1.75X70-MM) | 4 | |
| 5084246 | 10 ADAPTER-FAN | 1 | |
| 5698585 | 11 DRIVE GP-FAN | 1 | |
| 6C3241 | 12 BOLT (1/2-13X1.5-IN) | 2 | |
| 5P8245 | 13 WASHER-HARD (13.5X25.5X3-MM THK) | 2 | |
| 8T4121 | 14 WASHER-HARD (11X21X2.5-MM THK) | 2 | |
| 8T4136 | 15 BOLT (M10X1.5X25-MM) | 1 | |
| 8T4178 | 16 BOLT (M10X1.5X90-MM) | 1 | |
| 8T4223 | 17 WASHER-HARD (13.5X25.5X3-MM THK) | 6 | |
| 8T4244 | 18 NUT (M12X1.75-THD) | 4 | |
| 8T4896 | 19 WASHER-HARD (10.2X18.5X2.5-MM THK) | 6 | |
| 9B7237 | 20 BOLT (3/8-16X1.25-IN) | 6 |
