System And Components
521-3638 COVER GP-CYLINDER BLOCKS/N K1H1-UP
Group No: 521-3638
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1N2914 | 1 COVER-CYLINDER BLOCK SIDE | 13 | |
| 8R0721 | 2 SPACER (11X16X35-MM THK) | 6 | |
| 2720759 | 3 SEAL | 15 | |
| 3389390 | 4 LOCKWASHER | 46 | |
| 3736713 | 5 COVER | 1 | |
| 4500541 | 6 COVER-CYLINDER BLOCK | 1 | |
| 2032789 | 7 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 3523964 | 8 CLIP (LADDER) | 6 | |
| 7X7729 | 9 WASHER (11X25X3-MM THK) | 6 | |
| 8T0722 | 10 BOLT-LOCKING (M10X1.5X30-MM) | 1 | |
| 8T4121 | 11 WASHER-HARD (11X21X2.5-MM THK) | 1 | |
| 8T5035 | 12 BOLT (M10X1.5X65-MM) | 6 | |
| 9X2125 | 13 BOLT-LOCKING (M10X1.5X25-MM) | 46 |
