System And Components
461-7558 LINES GP-HOISTS/N HRT107-UP
Group No: 461-7558
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5C9762 | 1 MANIFOLD | 1 | |
| 5P4272 | 2 UNION | 1 | |
| 6V3482 | 3 CAP AS | 2 | |
| 8W2273 | 4 ADAPTER | 2 | |
| 1645567 | 5 COUPLER AS-QUICK DISCONNECT (MALE) | 1 | |
| 6V3965 | FITTING (QUICK DISCONNECT) | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 2067013 | 6 FASTENER | 2 | |
| 2147568 | 7 SEAL-O-RING | 2 | |
| 2260835 | 8 VALVE GP-PRESSURE REDUCING (HOIST PILOT OIL) | 1 | |
| 2428024 | 9 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 2428023 | BRACKET | 1 | |
| 2638522 | 10 SPACER | 2 | |
| 3170799 | 11 PLATE AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 4350692 | 12 PLATE-COVER | 1 | |
| 4350693 | 13 PLATE-COVER | 4 | |
| 4423390 | 14 BRACKET AS | 1 | |
| 9C6809 | BLOCK (M10X1.5-MM) | 1 | |
| 4423505 | 15 FLANGE & MOUNTING GP | 1 | |
| 4423506 | 16 FLANGE & MOUNTING GP | 1 | |
| 4532601 | 17 ADAPTER AS | 2 | |
| 2287094 | SEAL-O-RING | 1 | |
| 4345383 | ELBOW | 1 | |
| 4635810 | 18 BRACKET AS | 1 | |
| 8T3612 | NUT-WELD (M8X1.25-THD) | 2 | |
| 0914537 | BOSS-THREADED (M6X1X12-MM) | 2 | |
| 4635813 | 19 TUBE AS | 1 | |
| 4635816 | 20 TUBE AS | 1 | |
| 4635867 | 21 HOSE AS | 1 | |
| 4689700 | 22 CLAMP-HALF | 2 | |
| 4727058 | 23 FILTER AS-OIL (BRAKE COOLING, HOIST) | 2 | |
| 4176162 | FILTER-OIL | 1 | |
| 4538935 | COVER AS-FILTER (CARTRIDGE, OIL) | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 3603692 | PLUG (9/16-18-THD) | 1 | |
| 4934313 | 24 BRACKET AS | 1 | |
| 4934314 | 25 BRACKET AS | 1 | |
| 4327911 | RAIL-MOUNTING (26-CM) | ||
| 5175461 | 26 CLAMP-HALF | 8 | |
| 5334159 | 27 BOLT AS | 4 | |
| 1017398 | 28 BOLT-SOCKET HEAD (M10X1.5X40-MM) | 8 | |
| 1313025 | 29 FLANGE-SPLIT | 4 | |
| 1358573 | 30 BOLT AS | 1 | |
| 1745907 | 31 CLIP | 4 | |
| 1833399 | 32 CONNECTOR AS | 3 | |
| 6V8636 | CONNECTOR | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 2287089 | SEAL-O-RING | 1 | |
| 1907673 | 33 SEAL-O-RING | 3 | |
| 1912962 | 34 SEAL-O-RING | 11 | |
| 1P4578 | 35 FLANGE-HALF | 8 | |
| 1P4579 | 36 FLANGE-HALF | 4 | |
| 1P4582 | 37 FLANGE-HALF | 2 | |
| 2343544 | 38 SEAL-O-RING | 2 | |
| 2471437 | 39 VALVE GP-CONTROL (BRAKE COOLING, HOIST) | 1 | |
| 2977968 | 40 FITTING | 2 | |
| 3048037 | 41 CONNECTOR AS | 1 | |
| 6V9872 | CONNECTOR | 1 | |
| 2147566 | SEAL-O-RING | 1 | |
| 2287089 | SEAL-O-RING | 1 | |
| 3196233 | 42 TEE AS | 1 | |
| 6V8782 | TEE | 1 | |
| 2287090 | SEAL-O-RING | 2 | |
| 2385080 | SEAL-O-RING | 1 | |
| 3196240 | 43 CONNECTOR AS | 4 | |
| 6V9873 | CONNECTOR | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 2287090 | SEAL-O-RING | 1 | |
| 3196248 | 44 UNION AS | 2 | |
| 5P9560 | UNION | 1 | |
| 2385082 | SEAL-O-RING | 2 | |
| 3293356 | 45 NUT (M12X1.75-THD) | 3 | |
| 3295518 | 46 ADAPTER AS | 1 | |
| 8T2353 | ADAPTER | 1 | |
| 2147566 | SEAL-O-RING | 1 | |
| 3309735 | 47 ELBOW AS | 2 | |
| 8T3491 | ELBOW | 1 | |
| 2385082 | SEAL-O-RING | 1 | |
| 3445675 | 48 NUT (M10X1.5-THD) | 4 | |
| 3D8908 | 49 COVER | 1 | |
| 4423395 | 50 BLOCK GP-HYDRAULIC (ADAPTER) | 1 | |
| 8B7997 | BOLT-SOCKET HEAD (1/2-13X2-IN) | 4 | |
| 8T0568 | SEAL-O-RING | 1 | |
| 4423394 | BLOCK-ADAPTER | 1 | |
| 4423402 | 51 HOSE AS | 2 | |
| 4725725 | 52 HOSE AS | 2 | |
| 4792171 | 53 BOLT AS | 2 | |
| 4792172 | 54 BOLT AS | 1 | |
| 5031358 | 55 NUT (M12X1-THD) | 8 | |
| 5703586 | 56 HOSE AS | 1 | |
| 5885202 | 57 TUBE AS | 1 | |
| 5P8939 | 58 GROMMET | 1 | |
| 5P9299 | 59 CLIP (LOOP) | 1 | |
| 6V0852 | 60 CAP-DUST | 1 | |
| 6V1572 | 61 CLIP (SLOT) | 4 | |
| 6V1573 | 62 CLIP (TAB) | 4 | |
| 6V1875 | 63 GROMMET | 4 | |
| 6V4590 | 64 SEAL-O-RING | 2 | |
| 6V9830 | 65 CAP (ORFS) | 1 | |
| 7X0315 | 66 BOLT (7/16-14X3.25-IN) | 8 | |
| 7X2550 | 67 BOLT (M12X1.75X110-MM) | 8 | |
| 7X2553 | 68 BOLT (M16X2X40-MM) | 5 | |
| 8C8451 | 69 BOLT (M6X1X40-MM) | 2 | |
| 8T1889 | 70 CLIP (SLOT) | 1 | |
| 8T1890 | 71 CLIP (TAB) | 1 | |
| 8T4121 | 72 WASHER-HARD (11X21X2.5-MM THK) | 7 | |
| 8T4139 | 73 BOLT (M12X1.75X30-MM) | 2 | |
| 8T4176 | 74 BOLT (M12X1.75X90-MM) | 4 | |
| 8T4182 | 75 BOLT (M10X1.5X45-MM) | 2 | |
| 8T4184 | 76 BOLT (M12X1.75X45-MM) | 3 | |
| 8T4192 | 77 BOLT (M12X1.75X25-MM) | 8 | |
| 8T4194 | 78 BOLT (M12X1.75X50-MM) | 8 | |
| 8T4195 | 79 BOLT (M10X1.5X30-MM) | 1 | |
| 8T4223 | 80 WASHER-HARD (13.5X25.5X3-MM THK) | 52 | |
| 8T4224 | 81 WASHER-HARD (8.8X16X2-MM THK) | 2 | |
| 8T4648 | 82 BOLT (M12X1.75X70-MM) | 4 | |
| 8T5360 | 83 WASHER (12X22.5X2.5-MM THK) | 8 | |
| 8T6870 | 84 BOLT (M8X1.25X70-MM) | 2 | |
| 8T8916 | 85 BOLT (7/16-14X1.5-IN) | 8 | |
| 8T8919 | 86 BOLT (1/2-13X1.75-IN) | 12 | |
| 9X8256 | 87 WASHER (6.6X12X2-MM THK) | 2 | |
| 9X8257 | 88 WASHER (17.5X30X3.5-MM THK) | 5 | |
| 4652347 | 89 HOSE AS | 2 |
