System And Components
512-7643 LINES GP-EXHAUST COMBUSTIONS/N FKB1-UP
Group No: 512-7643
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1640150 | 1 SPACER (9X20X20-MM THK) | 1 | |
| 2888580 | 2 CLAMP-FUEL LINE | 6 | |
| 8T4224 | 3 WASHER-HARD (8.8X16X2-MM THK) | 5 | |
| 3586942 | 4 HOSE AS | 1 | |
| 3757817 | 5 BRACKET AS | 1 | |
| 3840988 | 6 HOSE & TUBE AS | 1 | |
| 5462074 | 7 TUBE AS (COOLANT) | 1 | |
| 4182056 | 8 HOSE | 1 | |
| 4288808 | 9 CLAMP-HOSE | 6 | |
| 4679633 | 10 HOSE | 1 | |
| 4719926 | 11 TANK AS (WATER) | 1 | |
| 5127641 | 12 HOSE | 1 | |
| 0307946 | 13 ELBOW | 2 | |
| 2261388 | 14 SPACER (9X20X10-MM THK) | 4 | |
| 8T7547 | 15 BOLT (M8X1.25X30-MM) | 4 | |
| 3320012 | 16 CLIP (LOOP) | 2 | |
| 3422136 | 17 CLIP (LOOP) | 2 | |
| 9X8256 | 18 WASHER (6.6X12X2-MM THK) | 3 | |
| 8T4971 | 19 BOLT (M6X1X30-MM) | 1 | |
| 7X2533 | 20 BOLT (M6X1X35-MM) | 1 | |
| 3441209 | 21 BOLT (M8X1.25X50-MM) | 1 | |
| 3445673 | 22 NUT (M6X1-THD) | 1 | |
| 5462073 | 23 HOSE & TUBE AS | 1 | |
| 6V9027 | 24 SEAL-O-RING | 6 | |
| 9S8002 | 25 PLUG (7/16-20-THD) | 4 |
