System And Components
502-4024 WIRING GP-ENGINES/N FKB1-UP
Group No: 502-4024
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7K1181 | 1 STRAP-CABLE | 17 | |
| 2566453 | 2 SENSOR-TEMPERATURE (2-PIN)(AIR INTAKE) | 1 | |
| 2764836 | 3 SWITCH-PRESSURE (24-VOLT)(AIR CLEANER) | 1 | |
| 1305300 | 4 CLIP | 2 | |
| 1325789 | 5 CLIP (LADDER) | 3 | |
| 2385080 | 6 SEAL-O-RING | 1 | |
| 3101898 | 7 CLIP (LADDER) | 2 | |
| 3513525 | 8 CLIP | 1 | |
| 3523964 | 9 CLIP (LADDER) | 1 | |
| 3523968 | 10 CLIP (LADDER) | 2 | |
| 1028802 | 11 KIT-RECEPTACLE (2-PIN) | 1 | |
| 4309454 | 12 SENSOR GP-LIQUID LEVEL (COOLANT) | 1 | |
| 4P7581 | 13 CLIP (LADDER) | 2 | |
| 4P8134 | 14 CLIP (LADDER) | 1 | |
| 5069522 | 15 HARNESS AS-ENGINE | 1 | |
| 8T4121 | 16 WASHER-HARD (11X21X2.5-MM THK) | 9 | |
| 8T4136 | 17 BOLT (M10X1.5X25-MM) | 9 | |
| 8T4189 | 18 BOLT (M8X1.25X20-MM) | 1 | |
| 8T4224 | 19 WASHER-HARD (8.8X16X2-MM THK) | 1 | |
| 8T8737 | 20 PLUG-SEAL | 2 |
