System And Components
Assembly
100%

268-3002 HEAD GP-PUMPS/N FKB1-UP

Group No: 268-3002
Part NumberPart NameQty
17725211 COVER GP-PUMP2
4J5573SEAL-O-RING1
6E3283LOCKNUT (M12X1.75-THD)1
8T2503BOLT-SOCKET HEAD (M14X2X35-MM)4
9T3929PLUG AS1
6E5479SEAL1
9X2403SETSCREW-HEX SOCKET (M12X1.75X50-MM)1
1237562SEAL-O-RING1
27035212 VALVE GP-PUMP CONTROL (PRESSURE COMPENSATOR)1
17725233 HOUSING1
17725244 GASKET1
17725255 PISTON2
17725266 ROD2
26830037 SPACER2
17725288 SPRING2
24789469 PISTON2
124988410 PIN-THREADED2
7X255311 BOLT (M16X2X40-MM)2
247894712 RING4
8T239313 BOLT-SOCKET HEAD (M16X2X60-MM)8
3E800814 BOLT-SOCKET HEAD (M16X2X90-MM)4
159766615 DOWEL2
120439416 PLUG-BREAK OFF1
123201717 PLUG-BREAK OFF1
