System And Components
503-4858 DOOR GP-ACCESSS/N FKB1-UP
Group No: 503-4858
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5163695 | 1 BRACKET | 1 | |
| 6V7636 | 2 PIN AS-SPRING | 2 | |
| 6V8073 | 3 LINK-CONNECTING | 1 | |
| 1107524 | 4 BUTTON | 6 | |
| 1149284 | 5 BUMPER | 2 | |
| 2583764 | 6 STRIKER AS | 1 | |
| 3463811 | 7 NUT-SQUARE | 1 | |
| 4460368 | 8 PLATE AS | 1 | |
| 5077526 | 9 HINGE AS | 1 | |
| 5153165 | 10 WINDOW | 1 | |
| 5163374 | 11 HANDLE AS | 1 | |
| 8T4180 | 12 SCREW-MACHINE (M5X0.8X20-MM) | 4 | |
| 5163696 | 13 FRAME AS | 1 | |
| 8T3612 | NUT-WELD (M8X1.25-THD) | 5 | |
| 1950936 | INSERT-THREADED (M6X1-THD) | 4 | |
| 5163706 | 14 LATCH AS | 1 | |
| 3445674 | 15 NUT (M8X1.25-THD) | 2 | |
| 8T4908 | 16 BOLT (M8X1.25X25-MM) | 7 | |
| 8T4189 | 17 BOLT (M8X1.25X20-MM) | 5 | |
| 8Y6386 | 18 SEAL-HANDLE | 1 | |
| 5P4116 | 19 WASHER-HARD (8.8X20.5X2-MM THK) | 12 | |
| 9X2040 | 20 SCREW-TRUSS HEAD (M10X1.5X25-MM) | 2 | |
| 9X2045 | 21 SCREW-TRUSS HEAD (M6X1X20-MM) | 8 | |
| 3641427 | 22 SEAL (446-CM) |
