558-1483 DOOR GP-CABS/N FKB1-UP

Group No: 558-1483
Part NumberPart NameQty
57229311 LEVER1
09095542 STUD-BALL2
19150773 STRAP4
19847764 WASHER-HARD (8.8X20X8-MM THK)2
24743325 PLATE1
28192176 BRACKET AS1
28221547 BRACKET AS1
8T3612NUT-WELD (M8X1.25-THD)1
28230078 SCREW-FLAT HEAD (M8X1.25X30-MM)12
36953159 STRUT AS1
3614806CLIP2
3E435210 WASHER-HARD (8.8X20.5X2.5-MM THK)12
510293511 PLATE1
510293612 PLATE1
581343313 STRIKER AS1
510293714 PLATE1
510293815 PLATE1
510297516 LATCH AS1
555460517 LINK AS1
6V8185NUT (1/4-20-THD)1
1085471CLEVIS1
574997818 STRAP2
555460619 LINK AS1
6V8185NUT (1/4-20-THD)1
1085471CLEVIS1
561092020 DOOR AS-CAB1
8T3612NUT-WELD (M8X1.25-THD)62
1889038BOSS (M6X1.6X40-MM)4
510208321 HINGE AS1
581525422 BRACKET AS1
8T3490NUT-WELD (M10X1.5-THD)2
569997423 COVER1
585028724 COVER AS1
6V268725 SCREW-PAN HEAD (10-24X1-IN)4
6V763626 PIN AS-SPRING2
6V822527 NUT (M6X1-THD)2
7X057928 WASHER-HARD (8.8X25.5X2-MM THK)41
7X253729 BOLT (M8X1.25X35-MM)2
8T350430 HANDLE AS-INSIDE1
8T419531 BOLT (M10X1.5X30-MM)2
8T418932 BOLT (M8X1.25X20-MM)45
8T422433 WASHER-HARD (8.8X16X2-MM THK)2
8T490834 BOLT (M8X1.25X25-MM)8
8T754735 BOLT (M8X1.25X30-MM)2
8T793436 WASHER-HARD (11X21X5-MM THK)2
8Y461437 SEAL-HANDLE1
8Y635938 HANDLE AS1
8Y4501SPRING-HANDLE1
2S138139 SPRING1
9X204140 SCREW-TRUSS HEAD (M10X1.5X20-MM)3
9X204441 SCREW-TRUSS HEAD (M6X1X16-MM)4
9X254642 BOLT (M6X1X20-MM)2
9X825643 WASHER (6.6X12X2-MM THK)2
5P594244 SEAL (0.6-M)
178889445 SEAL (465-CM)
