System And Components
Assembly
100%

572-5694 MODULE GP-COOLINGS/N SJN1-UP

Group No: 572-5694
Part NumberPart NameQty
57256951 CORE AS-OIL COOLER1
57256962 CORE AS-RADIATOR1
57257003 CORE AS-AFTERCOOLER1
41950934 MOUNT AS8
8T41845 BOLT (M12X1.75X45-MM)8
6V65636 WASHER (13.5X40X5-MM THK)8
8T41957 BOLT (M10X1.5X30-MM)26
8T41868 BOLT (M10X1.5X40-MM)6
7X77299 WASHER (11X25X3-MM THK)38
8T412110 WASHER-HARD (11X21X2.5-MM THK)38
243228911 MOUNT AS4
5P107612 WASHER-HARD (13.5X30X4-MM THK)4
8T413613 BOLT (M10X1.5X25-MM)6
8T419614 BOLT (M10X1.5X35-MM)4
8T418915 BOLT (M8X1.25X20-MM)6
8T490816 BOLT (M8X1.25X25-MM)2
5P411617 WASHER-HARD (8.8X20.5X2-MM THK)8
8T422418 WASHER-HARD (8.8X16X2-MM THK)14
8C641319 SPRING AS-GAS (HOOD)1
090955420 STUD-BALL2
578461321 FRAME AS1
578461522 BRACKET AS1
578461623 BRACKET AS1
578461724 BRACKET AS1
578461825 BRACKET AS1
578461926 BRACKET1
578462027 BRACKET1
578462128 SUPPORT AS2
578462229 CHANNEL2
578462330 FRAME AS1
578462431 HINGE AS2
578462532 BRACKET AS1
578462733 BRACKET1
578462834 BRACKET1
578463035 PLATE AS1
578463136 PLATE AS1
