System And Components
510-8132 CAMERA GP -REARS/N SJN1-UP
Group No: 510-8132
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7K1181 | 1 STRAP-CABLE | 4 | |
| 0965962 | 2 WASHER-HARD (3.4X7X0.8-MM THK) | 2 | |
| 3C6969 | 3 NUT (M3X0.5-THD) | 2 | |
| 4512536 | 4 BRACKET AS | 1 | |
| 5128671 | 5 CAMERA AS | 1 | |
| 5159339 | 6 SWITCH (ETHERNET) | 1 | |
| 5161358 | 7 PLATE | 1 | |
| 5194094 | 8 CONNECTOR AS | 1 | |
| 5194095 | 9 CONNECTOR AS | 1 | |
| 5194096 | 10 CONNECTOR AS | 1 | |
| 5255289 | 11 LAMP GP-HEAD (24-VOLT, 40-WATT, LED)(LOW BEAM) | 1 | |
| 5455387 | 12 GASKET | 2 | |
| 5455388 | 13 PLATE | 2 | |
| 5455391 | 14 PLATE-COVER | 2 | |
| 6V9505 | 15 SCREW-MACHINE (M3X0.5X25-MM) | 2 | |
| 7I2673 | 16 STRAP-CABLE | 6 | |
| 7X7729 | 17 WASHER (11X25X3-MM THK) | 9 | |
| 8T0389 | 18 LOCKNUT (M10X1.5-THD) | 1 | |
| 8T4121 | 19 WASHER-HARD (11X21X2.5-MM THK) | 10 | |
| 8T4137 | 20 BOLT (M10X1.5X20-MM) | 2 | |
| 8T4195 | 21 BOLT (M10X1.5X30-MM) | 17 | |
| 9R2860 | 22 SPACER (11X16.5X11-MM THK) | 8 |
