System And Components
502-6623 LIGHTING GP-FLOOD & HEADS/N SJN1-UP
Group No: 502-6623
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4512536 | 1 BRACKET AS | 2 | |
| 4590177 | 2 LAMP GP-FLOOD (LH) | 1 | |
| 5255289 | 3 LAMP GP-HEAD (24-VOLT, 40-WATT, LED) | 2 | |
| 5146900 | 4 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 2 | |
| 5146901 | 5 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 2 | |
| 5146902 | 6 BRACKET AS | 1 | |
| 7T1099 | LINK | 3 | |
| 5063240 | BOSS AS | 1 | |
| 5146903 | 7 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 6 | |
| 5146904 | 8 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 6 | |
| 4I3090 | 9 SEAL | 8 | |
| 7X7729 | 10 WASHER (11X25X3-MM THK) | 18 | |
| 8T0389 | 11 LOCKNUT (M10X1.5-THD) | 2 | |
| 8T4192 | 12 BOLT (M12X1.75X25-MM) | 8 | |
| 8T4195 | 13 BOLT (M10X1.5X30-MM) | 18 | |
| 8T4223 | 14 WASHER-HARD (13.5X25.5X3-MM THK) | 8 |
