System And Components
Assembly
100%

498-5439 HOOD GPS/N SJN1-UP

Group No: 498-5439
Part NumberPart NameQty
57106351 SEAL1
5U61812 PAD2
21280213 PLATE2
25176314 PLATE1
25176325 PLATE1
36238516 STRIP1
36238567 STRIP1
50867558 COVER1
51498279 GUSSET AS1
8T3597NUT-WELD (M12X1.75-THD)2
515147410 STRIP1
112392611 BOLT (M20X2.5X110-MM)2
344567512 NUT (M10X1.5-THD)4
513711813 SEAL AS1
8T4121WASHER-HARD (11X21X2.5-MM THK)4
8T4196BOLT (M10X1.5X35-MM)4
527933614 GUSSET1
527936615 STEP1
565236016 HOOD GP1
565237417 BRACKET AS1
565237518 GUSSET AS1
8T3597NUT-WELD (M12X1.75-THD)2
565237819 SEAL1
565237920 PLATE1
565241521 SEAL1
571061722 COVER AS-HOOD1
6V768823 LOCKNUT (M20X2.5-THD)2
6V894924 NUT (M10X1.5-THD)2
7X255225 BOLT (M16X2X30-MM)3
7X772926 WASHER (11X25X3-MM THK)4
8T412127 WASHER-HARD (11X21X2.5-MM THK)30
8T413628 BOLT (M10X1.5X25-MM)8
8T418329 BOLT (M12X1.75X40-MM)8
8T418630 BOLT (M10X1.5X40-MM)2
8T419531 BOLT (M10X1.5X30-MM)6
8T419632 BOLT (M10X1.5X35-MM)10
8T422333 WASHER-HARD (13.5X25.5X3-MM THK)18
8T495634 BOLT (M12X1.75X35-MM)10
8T500535 BOLT (M10X1.5X70-MM)2
8T733836 BOLT (M16X2X45-MM)4
9X825737 WASHER (17.5X30X3.5-MM THK)7
6V139238 SEAL (0.8-M)
