System And Components
501-7059 LINES GP-SAWS/N SJN1-UP
Group No: 501-7059
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5682728 | 1 PLATE | 1 | |
| 1P4578 | 2 FLANGE-HALF | 2 | |
| 2P1293 | 3 LOCKNUT (1-3/16-12-THD) | 11 | |
| 6V0400 | 4 FLANGE-HALF | 2 | |
| 6V0852 | 5 CAP-DUST | 1 | |
| 6V9172 | 6 NUT (1-7/16-12-THD) | 1 | |
| 8T7934 | 7 WASHER-HARD (11X21X5-MM THK) | 4 | |
| 9U7000 | 8 ADAPTER AS | 1 | |
| 2S4078 | SEAL-O-RING | 1 | |
| 5P7506 | ELBOW | 1 | |
| 1049693 | 9 FLANGE | 5 | |
| 1244287 | 10 FLANGE-SPLIT | 4 | |
| 2208660 | 11 MANIFOLD | 1 | |
| 2501488 | 12 TEE AS | 1 | |
| 5K9090 | SEAL-O-RING | 3 | |
| 1547159 | TEE | 1 | |
| 2627873 | 13 WASHER (30.5X48X2-MM THK) | 20 | |
| 3355321 | 14 SENSOR GP-PRESSURE (INTAKE MANIFOLD)(LOAD SENSING) | 1 | |
| 3892246 | 15 PLATE | 1 | |
| 4590574 | 16 ELBOW AS | 1 | |
| 2385086 | SEAL-O-RING | 1 | |
| 4590573 | ADAPTER-ELBOW | 1 | |
| 0950670 | 17 BOLT (M12X1.75X45-MM) | 8 | |
| 1017398 | 18 BOLT-SOCKET HEAD (M10X1.5X40-MM) | 8 | |
| 1017404 | 19 BOLT-SOCKET HEAD (M10X1.5X30-MM) | 20 | |
| 1053478 | 20 BOLT-SOCKET HEAD (M10X1.5X35-MM) | 4 | |
| 1313025 | 21 FLANGE-SPLIT | 2 | |
| 1488317 | 22 CONNECTOR AS | 2 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 5K9090 | SEAL-O-RING | 1 | |
| 6V8714 | CONNECTOR | 1 | |
| 1488334 | 23 CONNECTOR AS | 1 | |
| 2S4078 | SEAL-O-RING | 1 | |
| 6V8400 | SEAL-O-RING | 1 | |
| 8T3611 | CONNECTOR | 1 | |
| 1488362 | 24 ELBOW AS | 2 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 5K9090 | SEAL-O-RING | 1 | |
| 8T6684 | ELBOW | 1 | |
| 1488376 | 25 ELBOW AS | 1 | |
| 6V8983 | ELBOW | 1 | |
| 6V9746 | SEAL-O-RING | 2 | |
| 1645567 | 26 COUPLER AS-QUICK DISCONNECT (MALE) | 1 | |
| 6V3965 | FITTING (QUICK DISCONNECT) | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 1P3703 | 27 SEAL-RECTANGULAR | 6 | |
| 2162817 | 28 UNION AS | 1 | |
| 6V8400 | SEAL-O-RING | 2 | |
| 1109160 | UNION | 1 | |
| 2203246 | 29 CLAMP | 1 | |
| 3J1907 | 30 SEAL-O-RING | 1 | |
| 4264085 | 31 ELBOW AS | 2 | |
| 4J5267 | SEAL-O-RING | 1 | |
| 5K9090 | SEAL-O-RING | 1 | |
| 4390448 | ADAPTER-ELBOW | 1 | |
| 4345383 | 32 ELBOW | 1 | |
| 1P3702 | 33 SEAL-RECTANGULAR | 1 | |
| 4J0522 | 34 SEAL-O-RING | 2 | |
| 5406858 | 35 HOSE AS | 1 | |
| 5563974 | 36 TUBE AS | 1 | |
| 5563975 | 37 TUBE AS | 1 | |
| 5563976 | 38 TUBE AS | 1 | |
| 5563977 | 39 TUBE AS | 1 | |
| 5596382 | 40 HOSE AS | 1 | |
| 5596384 | 41 HOSE AS | 1 | |
| 5828183 | 42 HOSE AS | 1 | |
| 5603615 | 43 TUBE AS | 1 | |
| 5603616 | 44 TUBE AS | 1 | |
| 5603619 | 45 TUBE AS | 1 | |
| 5637410 | 46 HOSE AS | 1 | |
| 5677943 | 47 TUBE AS | 1 | |
| 5677945 | 48 TUBE AS | 1 | |
| 5677946 | 49 TUBE AS | 1 | |
| 5683668 | 50 PLATE AS | 1 | |
| 7T1099 | LINK | 2 | |
| 9R2613 | BOSS-WELD (M10X1.5X25-MM) | 1 | |
| 5K9090 | 51 SEAL-O-RING | 5 | |
| 6V8400 | 52 SEAL-O-RING | 1 | |
| 6V9173 | 53 NUT-BULKHEAD (1-11/16-12-THD) | 1 | |
| 6V9746 | 54 SEAL-O-RING | 10 | |
| 6V9833 | 55 CAP | 1 | |
| 8T4121 | 56 WASHER-HARD (11X21X2.5-MM THK) | 12 | |
| 8T4223 | 57 WASHER-HARD (13.5X25.5X3-MM THK) | 8 | |
| 1503058 | 58 TEE AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 8C8431 | TEE | 1 | |
| 1504043 | 59 CONNECTOR AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 6V9873 | CONNECTOR | 1 | |
| 1488370 | 60 ELBOW AS | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 6V9851 | ELBOW | 1 | |
| 5828184 | 61 HOSE AS | 1 | |
| 8T6685 | 62 BOLT (M10X1.5X110-MM) | 4 |
