System And Components
502-4965 LINES GP-SAWS/N SJN1-UP
Group No: 502-4965
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5682728 | 1 PLATE | 1 | |
| 0950670 | 2 BOLT (M12X1.75X45-MM) | 8 | |
| 1017398 | 3 BOLT-SOCKET HEAD (M10X1.5X40-MM) | 8 | |
| 1017404 | 4 BOLT-SOCKET HEAD (M10X1.5X30-MM) | 20 | |
| 1049693 | 5 FLANGE | 5 | |
| 1053478 | 6 BOLT-SOCKET HEAD (M10X1.5X35-MM) | 4 | |
| 1244287 | 7 FLANGE-SPLIT | 4 | |
| 1313025 | 8 FLANGE-SPLIT | 2 | |
| 2208660 | 9 MANIFOLD | 1 | |
| 1488317 | 10 CONNECTOR AS | 2 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 5K9090 | SEAL-O-RING | 1 | |
| 6V8714 | CONNECTOR | 1 | |
| 1488327 | 11 CONNECTOR AS | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V8637 | CONNECTOR | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 1488334 | 12 CONNECTOR AS | 1 | |
| 2S4078 | SEAL-O-RING | 1 | |
| 6V8400 | SEAL-O-RING | 1 | |
| 8T3611 | CONNECTOR | 1 | |
| 1488362 | 13 ELBOW AS | 2 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 5K9090 | SEAL-O-RING | 1 | |
| 8T6684 | ELBOW | 1 | |
| 1488376 | 14 ELBOW AS | 2 | |
| 6V8983 | ELBOW | 1 | |
| 6V9746 | SEAL-O-RING | 2 | |
| 1645567 | 15 COUPLER AS-QUICK DISCONNECT (MALE) | 1 | |
| 6V3965 | FITTING (QUICK DISCONNECT) | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 1P3703 | 16 SEAL-RECTANGULAR | 6 | |
| 1P3704 | 17 SEAL-RECTANGULAR | 1 | |
| 1P4578 | 18 FLANGE-HALF | 2 | |
| 2162817 | 19 UNION AS | 1 | |
| 6V8400 | SEAL-O-RING | 2 | |
| 1109160 | UNION | 1 | |
| 2203246 | 20 CLAMP | 1 | |
| 2501488 | 21 TEE AS | 1 | |
| 5K9090 | SEAL-O-RING | 3 | |
| 1547159 | TEE | 1 | |
| 2627873 | 22 WASHER (30.5X48X2-MM THK) | 20 | |
| 2P1293 | 23 LOCKNUT (1-3/16-12-THD) | 12 | |
| 3355321 | 24 SENSOR GP-PRESSURE (INTAKE MANIFOLD)(LOAD SENSING) | 1 | |
| 3892246 | 25 PLATE | 1 | |
| 3J1907 | 26 SEAL-O-RING | 1 | |
| 4264085 | 27 ELBOW AS | 2 | |
| 4J5267 | SEAL-O-RING | 1 | |
| 5K9090 | SEAL-O-RING | 1 | |
| 4390448 | ADAPTER-ELBOW | 1 | |
| 4345383 | 28 ELBOW | 1 | |
| 4590574 | 29 ELBOW AS | 1 | |
| 2385086 | SEAL-O-RING | 1 | |
| 4590573 | ADAPTER-ELBOW | 1 | |
| 4929278 | 30 HOSE AS | 1 | |
| 5K9090 | 31 SEAL-O-RING | 5 | |
| 4J0522 | 32 SEAL-O-RING | 1 | |
| 5406858 | 33 HOSE AS | 1 | |
| 5563974 | 34 TUBE AS | 1 | |
| 5563975 | 35 TUBE AS | 1 | |
| 5563976 | 36 TUBE AS | 1 | |
| 5563977 | 37 TUBE AS | 1 | |
| 5596382 | 38 HOSE AS | 1 | |
| 5596384 | 39 HOSE AS | 1 | |
| 5828183 | 40 HOSE AS | 1 | |
| 5603615 | 41 TUBE AS | 1 | |
| 5603616 | 42 TUBE AS | 1 | |
| 5603619 | 43 TUBE AS | 1 | |
| 5637410 | 44 HOSE AS | 1 | |
| 5677943 | 45 TUBE AS | 1 | |
| 5677945 | 46 TUBE AS | 1 | |
| 5677946 | 47 TUBE AS | 1 | |
| 5683668 | 48 PLATE AS | 1 | |
| 7T1099 | LINK | 2 | |
| 9R2613 | BOSS-WELD (M10X1.5X25-MM) | 1 | |
| 1939230 | 49 VALVE GP-CHECK (SAW OIL SUPPLY) | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 1P3702 | 50 SEAL-RECTANGULAR | 1 | |
| 6V0400 | 51 FLANGE-HALF | 2 | |
| 6V0852 | 52 CAP-DUST | 1 | |
| 6V8400 | 53 SEAL-O-RING | 1 | |
| 6V9172 | 54 NUT (1-7/16-12-THD) | 1 | |
| 6V9173 | 55 NUT-BULKHEAD (1-11/16-12-THD) | 1 | |
| 6V9746 | 56 SEAL-O-RING | 10 | |
| 5828177 | 57 HOSE AS | 1 | |
| 8T4121 | 58 WASHER-HARD (11X21X2.5-MM THK) | 12 | |
| 8T4223 | 59 WASHER-HARD (13.5X25.5X3-MM THK) | 8 | |
| 8T6685 | 60 BOLT (M10X1.5X110-MM) | 4 | |
| 9U7000 | 61 ADAPTER AS | 1 | |
| 2S4078 | SEAL-O-RING | 1 | |
| 5P7506 | ELBOW | 1 | |
| 8T7934 | 62 WASHER-HARD (11X21X5-MM THK) | 4 | |
| 1503058 | 63 TEE AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 8C8431 | TEE | 1 | |
| 1504043 | 64 CONNECTOR AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 6V9873 | CONNECTOR | 1 | |
| 1488370 | 65 ELBOW AS | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 6V9851 | ELBOW | 1 | |
| 5828184 | 66 HOSE AS | 1 |
