System And Components
247-3782 COVER GP-CYLINDER BLOCK -CENTRAL STRUCTURES/N L4M1-UP
Group No: 247-3782
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1N2914 | 1 COVER-CYLINDER BLOCK SIDE | 16 | |
| 4W5015 | 2 COVER | 1 | |
| 5L5840 | 3 WASHER (9.25X16.92X1.83-MM THK) | 8 | |
| 7N3298 | 4 COVER-BLOCK | 2 | |
| 7N4945 | 5 GASKET | 2 | |
| 8N9992 | 6 COVER-CAMSHAFT | 8 | |
| 1A2029 | 7 BOLT (3/8-16X1.125-IN) | 88 | |
| 3496052 | 9 COVER-CAMSHAFT | 8 | |
| 2720758 | 10 SEAL | 8 | |
| 2720759 | 11 SEAL | 16 | |
| 2775833 | 12 SEAL | 8 | |
| 2301072 | 13 GASKET | 2 | |
| 0S1594 | 14 BOLT (3/8-16X1-IN) | 12 | |
| 0S1595 | 15 BOLT (1/2-13X1.25-IN) | 4 | |
| 1C2251 | 16 BOLT (3/8-16X1.87-IN) | 8 | |
| 5M2894 | 18 WASHER-HARD (10.2X18.5X2.5-MM THK) | 160 | |
| 5P8245 | 19 WASHER-HARD (13.5X25.5X3-MM THK) | 4 | |
| 6H6698 | 20 COVER | 2 | |
| 8T6761 | 21 PLUG-PIPE (1-11-1/2 NPT THD) | 1 | |
| 9X8872 | 23 BOLT-LOCKING (3/8-16X0.875-IN) | 60 | |
| 3321835 | 24 FILM-WARNING (HOT SURFACE, HANDS CLEAR) | 1 | |
| 2985631 | 25 PLATE-IDENTIFICATION (CAT) | 2 |
