372-9105 COVER GP-CYLINDER BLOCK -EXPLOSION RELIEFS/N HCY1-UP

Group No: 372-9105
Part NumberPart NameQty
1N29141 COVER-CYLINDER BLOCK SIDE13
4W50152 COVER1
5L58403 WASHER (9.25X16.92X1.83-MM THK)8
7N32984 COVER-BLOCK2
7N49455 GASKET2
8N85096 VALVE GP-EXPLOSION RELIEF (CRANKCASE)3
8N99927 COVER-CAMSHAFT8
34960528 COVER-CAMSHAFT8
23010729 GASKET2
272075810 SEAL8
272075911 SEAL16
277583312 SEAL8
0S159413 BOLT (3/8-16X1-IN)12
0S159514 BOLT (1/2-13X1.25-IN)4
1A202915 BOLT (3/8-16X1.125-IN)88
1C225116 BOLT (3/8-16X1.87-IN)8
5M289417 WASHER-HARD (10.2X18.5X2.5-MM THK)160
5P824518 WASHER-HARD (13.5X25.5X3-MM THK)4
6H669819 COVER2
8T676120 PLUG-PIPE (1-11-1/2 NPT THD)1
9X887221 BOLT-LOCKING (3/8-16X0.875-IN)60
298563122 PLATE-IDENTIFICATION (CAT)2
332183523 FILM-WARNING (HOT SURFACE, HANDS CLEAR)1
2W3584KIT-REPAIR (EXPLOSION RELIEF)1
