System And Components
560-9810 BRACKET GP-MOUNTING -CONSOLES/N FKJ1-UP
Group No: 560-9810
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3320195 | 1 CLIP | 2 | |
| 3B4607 | 2 PIN-COTTER | 1 | |
| 4956057 | 3 BUSHING | 8 | |
| 5000884 | 4 DAMPER (CYLINDER) | 1 | |
| 5208286 | 5 STRIKER | 1 | |
| 5609818 | 6 BRACKET AS | 1 | |
| 6V9632 | NUT-WELD (M6X1-THD) | 2 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 6C8608 | 7 PIN | 1 | |
| 7Y8561 | 8 BUMPER | 1 | |
| 8T4121 | 9 WASHER-HARD (11X21X2.5-MM THK) | 1 | |
| 8T4133 | 10 NUT (M10X1.5-THD) | 1 | |
| 9X2043 | 11 SCREW-TRUSS HEAD (M6X1X14-MM) | 2 | |
| 7X0579 | 12 WASHER-HARD (8.8X25.5X2-MM THK) | 4 | |
| 9X8256 | 13 WASHER (6.6X12X2-MM THK) | 1 | |
| 9X2616 | 14 SCREW-SOCKET (M8X1.25X16-MM) | 4 |
