System And Components
360-5393 DRIVE GP-FANS/N AT41-UP
Group No: 360-5393
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6N2538 | 1 BRACKET-FAN ADJUSTMENT | 1 | |
| 6N2547 | 2 ADAPTER-FAN BRACKET | 1 | |
| 7E4808 | 3 PLATE | 1 | |
| 4446555 | 4 BRACKET AS | 1 | |
| 4N0684 | 4A DOWEL | 1 | |
| 3330773 | 5 SPACER-SPECIAL | 1 | |
| 3330774 | 6 HUB | 1 | |
| 3330776 | 7 SPACER-SPECIAL | 1 | |
| 3332408 | 8 BALL BEARING | 2 | |
| 3623608 | 9 ADAPTER | 1 | |
| 0S1585 | 10 BOLT (1/2-13X1.5-IN) | 2 | |
| 1A2029 | 11 BOLT (3/8-16X1.125-IN) | 2 | |
| 1F7958 | 12 NUT-FULL (1/2-13-THD) | 4 | |
| 2D8155 | 13 STUD-TAPERLOCK (1/2-13X3.58-IN) | 4 | |
| 5M2894 | 14 WASHER-HARD (10.2X18.5X2.5-MM THK) | 2 | |
| 5P8245 | 15 WASHER-HARD (13.5X25.5X3-MM THK) | 4 | |
| 6H3956 | 16 PIN | 1 | |
| 6N0597 | 17 PULLEY-FAN DRIVE (4-GROOVE) | 1 | |
| 6V8801 | 18 NUT (3/8-16-THD) | 1 | |
| 7D1649 | 19 WASHER-HARD (13.5X32X5-MM THK) | 4 | |
| 9L5595 | 20 BOLT (3/8-16X5-IN) | 1 | |
| 9X8874 | 21 BOLT (1/2-13X3-IN) | 1 | |
| 9X8877 | 22 BOLT (1/2-13X5-IN) | 2 | |
| 4206942 | 23 SPACER (40.4X49X5-MM THK) | 1 |
