System And Components
346-9066 LINES GP-AIR COMPRESSORS/N AT41-UP
Group No: 346-9066
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3469067 | 1 HOSE AS | 1 | |
| 3469068 | 2 HOSE AS | 1 | |
| 3469069 | 3 HOSE AS | 1 | |
| 3485917 | 4 HOSE AS | 1 | |
| 3574571 | 5 ELBOW AS | 1 | |
| 6V6609 | SEAL-O-RING | 1 | |
| 1184728 | ELBOW | 1 | |
| 0017043 | 6 ELBOW | 1 | |
| 0054173 | 7 ELBOW | 1 | |
| 0308195 | 8 CONNECTOR | 1 | |
| 0L1143 | 9 BOLT (3/8-16X2.5-IN) | 1 | |
| 1003237 | 10 GROMMET | 2 | |
| 2385081 | 11 SEAL-O-RING | 2 | |
| 2385082 | 12 SEAL-O-RING | 1 | |
| 0974896 | 13 SPACER (12X20X23-MM THK) | 1 | |
| 2M9780 | 14 SEAL-O-RING | 1 | |
| 2N1287 | 15 ELBOW-FLARED | 1 | |
| 2N3378 | 16 ELBOW-FLARED | 1 | |
| 2P8511 | 17 ELBOW-FLARED | 1 | |
| 3095126 | 18 ADAPTER-TEE | 1 | |
| 3491209 | 19 CLIP | 3 | |
| 3537957 | 20 GROMMET | 2 | |
| 3P2298 | 21 ELBOW-FLARED | 1 | |
| 4H7655 | 22 CLAMP-TUBE | 2 | |
| 5M2894 | 23 WASHER-HARD (10.2X18.5X2.5-MM THK) | 3 | |
| 5P7970 | 24 NUT (M8X1.25-THD) | 1 | |
| 6V3940 | 25 BOLT (M8X1.25X25-MM) | 1 | |
| 8T1887 | 26 CLIP (SLOT) | 2 | |
| 8T1888 | 27 CLIP (TAB) | 2 | |
| 9M1974 | 28 WASHER-HARD (8.8X16X2-MM THK) | 2 | |
| 0S1571 | 29 BOLT (3/8-16X1.75-IN) | 1 | |
| 9X6458 | 30 WASHER-HARD (10.2X22.5X3-MM THK) | 2 | |
| 9Y2700 | 31 SPACER (11X20X42-MM THK) | 1 | |
| 3503656 | 32 BRACKET AS | 1 | |
| 0S1588 | 33 BOLT (3/8-16X1.25-IN) | 1 |
