System And Components
352-8042 LINES GP-TURBOCHARGER OILS/N AT41-UP
Group No: 352-8042
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 9M2564 | 1 CLAMP-TUBE | 6 | |
| 1978418 | 2 GASKET | 2 | |
| 1978419 | 3 GASKET (TURBOCHARGER) | 2 | |
| 7N9008 | 4 ELBOW | 2 | |
| 3520277 | 5 TUBE AS | 1 | |
| 3527354 | 6 TUBE AS | 1 | |
| 3555349 | 7 TUBE AS | 1 | |
| 3555351 | 8 TUBE AS | 1 | |
| 3850024 | 9 HOSE AS-OIL SUPPLY | 1 | |
| 0S1588 | 10 BOLT (3/8-16X1.25-IN) | 3 | |
| 3498519 | 11 ELBOW AS | 2 | |
| 6V9003 | ELBOW | 1 | |
| 2287091 | SEAL-O-RING | 1 | |
| 2385081 | SEAL-O-RING | 1 | |
| 1123540 | 12 SEAL-O-RING | 2 | |
| 1B2790 | 13 BOLT (5/16-18X1.375-IN) | 4 | |
| 2287093 | 14 SEAL-O-RING | 1 | |
| 3B1915 | 15 BOLT (3/8-16X1.375-IN) | 4 | |
| 5M2894 | 16 WASHER-HARD (10.2X18.5X2.5-MM THK) | 8 | |
| 5P5846 | 17 SEAL-O-RING | 2 | |
| 6V5782 | 18 BOLT (5/16-18X1.125-IN) | 4 | |
| 0S1594 | 19 BOLT (3/8-16X1-IN) | 2 | |
| 1003237 | 20 GROMMET | 1 | |
| 9M1974 | 21 WASHER-HARD (8.8X16X2-MM THK) | 8 | |
| 9S8752 | 22 NUT-FULL (3/8-16-THD) | 3 | |
| 3537952 | 23 GROMMET | 1 | |
| 3856148 | 24 BRACKET AS | 1 | |
| 8T1887 | 25 CLIP (SLOT) | 1 | |
| 8T1888 | 26 CLIP (TAB) | 1 | |
| 8T1897 | 27 CLIP (SLOT) | 1 | |
| 8T1898 | 28 CLIP (TAB) | 1 |
