System And Components
362-8903 LINES GP-TURBOCHARGER OILS/N AT41-UP
Group No: 362-8903
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8N0590 | 1 CLIP | 4 | |
| 1978418 | 2 GASKET | 2 | |
| 3641939 | 3 HOSE & TUBE AS | 1 | |
| 4451212 | 4 HOSE & TUBE AS | 1 | |
| 3712764 | 5 ELBOW | 2 | |
| 0S1616 | 6 BOLT (1/4-20X1-IN) | 2 | |
| 1978419 | 7 GASKET (TURBOCHARGER) | 2 | |
| 1A2029 | 8 BOLT (3/8-16X1.125-IN) | 4 | |
| 1B2790 | 9 BOLT (5/16-18X1.375-IN) | 8 | |
| 2287093 | 10 SEAL-O-RING | 2 | |
| 2395572 | 11 SEAL-INTEGRAL | 2 | |
| 2609219 | 12 CONNECTOR AS | 1 | |
| 6V8638 | CONNECTOR | 1 | |
| 2287090 | SEAL-O-RING | 1 | |
| 2385081 | SEAL-O-RING | 1 | |
| 5M2894 | 13 WASHER-HARD (10.2X18.5X2.5-MM THK) | 4 | |
| 9M1974 | 14 WASHER-HARD (8.8X16X2-MM THK) | 8 | |
| 1984775 | 16 WASHER-HARD (6.6X15X6-MM THK) | 2 | |
| 3309772 | 17 ELBOW AS | 1 | |
| 6V8624 | ELBOW | 1 | |
| 2287090 | SEAL-O-RING | 1 | |
| 2385081 | SEAL-O-RING | 1 | |
| 5P0537 | 18 WASHER-HARD (7.2X14.5X2-MM THK) | 4 | |
| 9S8750 | 19 NUT-FULL (1/4-20-THD) | 2 | |
| 3729139 | 20 HOSE & TUBE AS | 1 | |
| 3729140 | 21 HOSE & TUBE AS | 1 |
