System And Components
350-8629 LINES GP-TURBOCHARGER WATERS/N AT41-UP
Group No: 350-8629
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4P7233 | 1 GROMMET | 4 | |
| 8S4951 | 2 CAP (FLARED) | 1 | |
| 1178990 | 3 CLIP | 2 | |
| 3857034 | 5 BRACKET AS | 1 | |
| 1F0750 | 5A NUT-WELD (3/8-16-THD) | 1 | |
| 3857035 | 6 BRACKET AS | 1 | |
| 1F0750 | 6A NUT-WELD (3/8-16-THD) | 1 | |
| 3554677 | 7 BRACKET AS | 1 | |
| 1F0750 | 7A NUT-WELD (3/8-16-THD) | 1 | |
| 3554678 | 8 BRACKET AS | 1 | |
| 1F0750 | 8A NUT-WELD (3/8-16-THD) | 1 | |
| 3554684 | 9 HOSE AS-WATER | 1 | |
| 3554687 | 11 TUBE AS | 1 | |
| 3855634 | 12 HOSE & TUBE AS | 1 | |
| 3646733 | 13 HOSE & TUBE AS | 1 | |
| 3717252 | 14 TUBE AS-WATER | 1 | |
| 3649281 | 15 HOSE & TUBE AS | 1 | |
| 3649285 | 16 TUBE AS | 1 | |
| 3653499 | 17 BRACKET AS | 1 | |
| 1F0750 | 17A NUT-WELD (3/8-16-THD) | 1 | |
| 0307959 | 18 TEE-FLARED | 1 | |
| 0321270 | 19 TEE | 1 | |
| 0L1351 | 20 BOLT (3/8-16X0.875-IN) | 5 | |
| 0S0509 | 22 BOLT (3/8-16X0.75-IN) | 1 | |
| 0S1588 | 23 BOLT (3/8-16X1.25-IN) | 1 | |
| 0S1619 | 25 BOLT (3/8-16X3-IN) | 2 | |
| 1A2029 | 26 BOLT (3/8-16X1.125-IN) | 1 | |
| 1S0724 | 27 CLIP | 1 | |
| 2385080 | 28 SEAL-O-RING | 4 | |
| 2385082 | 29 SEAL-O-RING | 1 | |
| 2385084 | 30 SEAL-O-RING | 1 | |
| 2P8430 | 31 CONNECTOR | 1 | |
| 3118802 | 32 SPACER (10.5X19X57-MM THK) | 2 | |
| 3491209 | 34 CLIP | 3 | |
| 3P2298 | 35 ELBOW-FLARED | 1 | |
| 4H2633 | 36 CLIP | 3 | |
| 5M2894 | 37 WASHER-HARD (10.2X18.5X2.5-MM THK) | 11 | |
| 8M0505 | 38 ADAPTER | 1 | |
| 8M0547 | 39 ELBOW-FLARED (SWIVEL) | 3 | |
| 8M3175 | 40 WASHER-HARD (10.2X16X3-MM THK) | 2 | |
| 8T1887 | 41 CLIP (SLOT) | 4 | |
| 8T1888 | 42 CLIP (TAB) | 4 | |
| 9D2673 | 43 CONNECTOR-PORT | 3 | |
| 9F6343 | 44 CLAMP | 2 | |
| 9S8752 | 45 NUT-FULL (3/8-16-THD) | 3 | |
| 5S0003 | 46 NUT (5/16-18-THD) | 1 | |
| 6V6609 | 47 SEAL-O-RING | 1 | |
| 9M1974 | 48 WASHER-HARD (8.8X16X2-MM THK) | 1 | |
| 3855632 | 49 TUBE AS-WATER | 1 | |
| 3869666 | 50 TUBE AS-WATER | 1 |
